Gear Selector Drum
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1190460 Selector drum assembly | Selector drum assembly 5 Speed | 1 | $325.77 | Obsolete | View Details |
| 2 | T3331191 Screw, Pan/Hd, Tx, M6 x 20, Enc | Screw, Pan/Hd, Tx, M6 x 20, Enc | 1 | $2.10 | Available to order | 1 |
| 3 | T3800090 Bearing Ball, Unshld, 20x42x8 | Bearing Ball, Unshld, 20x42x8 | 1 | $7.62 | Available to order | 1 |
| 4 | T1190100 Detent Wheel | Detent Wheel PART NO LONGER AVAILABLE | 1 | $20.84 | Obsolete | View Details |
| 5 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 1 | $1.06 | Available to order | 1 |
| 6 | 3000008-T0301 Spirol pin | Spirol pin | 1 | $1.18 | Obsolete | View Details |
| 7 | T1190235 Gear actuating | Gear actuating | 1 | $26.65 | Obsolete | View Details |
| 8 | T1190325 Pawl | Pawl Lower | 1 | $10.40 | Obsolete | View Details |
| 9 | T1190085 Pawl | Pawl Upper | 1 | $11.62 | Obsolete | View Details |
| 10 | 1190300-T0301 Plunger | Plunger | 2 | $3.33 | Obsolete | View Details |
| 11 | 1190310-T0301 Spring plunger | Spring plunger | 2 | $5.03 | Obsolete | View Details |
| 12 | 1190200-T0301 Stop plate | Stop plate | 1 | $4.32 | Obsolete | View Details |
| 13 | T3332704 Screw, Torx, M6 x 14 | Screw, Torx, M6 x 14 M6 x 14mm | 2 | $5.24 | Available to order | 2 |
| 14 | T1190248 Indicator plate | Indicator plate | 1 | $21.15 | Obsolete | View Details |
| 15 | 3500006-T0301 Circlip | Circlip | 1 | $0.42 | Obsolete | View Details |
| 16 | T1190035 Selector shaft | Selector shaft | 1 | $27.91 | Available to order | 1 |
| 17 | 1190060-T0301 Selector fork | Selector fork 1st/3rd | 1 | $51.31 | Out of Stock | Notify Me |
| 18 | 1190070-T0301 Selector fork | Selector fork 5th/6th | 1 | $51.31 | Out of Stock | Notify Me |
| 19 | 1190080-T0301 Selector fork | Selector fork 2nd/4th | 1 | $78.09 | Obsolete | View Details |
| 20 | T3600143 O Ring, ID 9.1 x 1.6, Viton | O Ring, ID 9.1 x 1.6, Viton | 1 | $2.10 | Available to order | 1 |
| 21 | 1190110-T0301 Plate keeper | Plate keeper | 1 | $2.48 | Available to order | 1 |
| 22 | T3051069 Screw, Cap/Hd, M6 x 10, Enc, Raw | Screw, Cap/Hd, M6 x 10, Enc, Raw | 1 | $1.27 | Available to order | 1 |
| 23 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv | 1 | $2.00 | Available to order | 1 |
| 24 | 3550020-T0301 Sealing Washer, M10 | Sealing Washer, M10 | 1 | $0.90 | Obsolete | View Details |
| 25 | T1190494 Neutral Indicator Switch | Neutral Indicator Switch | 1 | $39.24 | Backorder — Late August 2026 | 1 |
