Transmission ENG NO 107969 »
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1180156 Sleeve Assy, Needle bearing | Sleeve Assy, Needle bearing | 1 | $63.70 | Available to order | 1 |
| 2 | T3500201 Circlip, EXT, 23.5 x 1.2 | Circlip, EXT, 23.5 x 1.2 | 1 | $4.36 | Available to order | 1 |
| 3 | T3800006 Bearing, Needle, K25x32x16 | Bearing, Needle, K25x32x16 | 2 | $17.21 | Available to order | 2 |
| 4 | T3555005 Washer, 25.5 x 38 x 1.5 | Washer, 25.5 x 38 x 1.5 | 2 | $3.70 | Available to order | 2 |
| 5 | T1180542 Gear input | Gear input 2nd | 1 | $65.81 | Obsolete | View Details |
| 6 | T1180536 Spacer | Spacer 6th | 1 | $59.07 | Obsolete | View Details |
| 7 | T3500003 Circlip, 32mm Shaft | Circlip, 32mm Shaft | 2 | $7.02 | Available to order | 2 |
| 8 | T1180543 Gear input | Gear input 3rd/4th | 1 | $156.14 | Obsolete | View Details |
| 9 | T1180281 Washer, Thrust, Input | Washer, Thrust, Input | 2 | $3.70 | Available to order | 2 |
| 10 | T1180525 Gear input | Gear input 5th | 1 | $128.28 | Obsolete | View Details |
| 11 | T1180541 Input shaft and gear | Input shaft and gear | 1 | $277.60 | Backorder — Early August 2026 | 1 |
| 12 | 3800002-T0301 Bearing, Ball, DG2868 GN1C3 | Bearing, Ball, DG2868 GN1C3 | 1 | $43.51 | Available to order | 1 |
| 13 | 1180160-T0301 Distance Sleeve | Distance Sleeve PART NO LONGER AVAILABLE | 1 | $1.80 | Obsolete | View Details |
| 14 | T3800132 Bearing, 30 x 62 x 16, DGB | Bearing, 30 x 62 x 16, DGB | 1 | $119.76 | Out of Stock | Notify Me |
| 15 | T1180550 Shaft output | Shaft output | 1 | $174.99 | Obsolete | View Details |
| 16 | T1180532 Gear output | Gear output 2nd | 1 | $149.35 | Obsolete | View Details |
| 17 | T1180291 Washer thrust | Washer thrust | 3 | $3.70 | Available to order | 3 |
| 18 | T3500202 Circlip | Circlip | 3 | $5.60 | Available to order | 3 |
| 19 | T1180576 Spacer | Spacer | 1 | $126.32 | Obsolete | View Details |
| 20 | T1180554 Gear output | Gear output 4th | 1 | $119.76 | Available to order | 1 |
| 21 | T1180776 Bush | Bush 3rd/4th | 1 | $58.92 | Available to order | 1 |
| 22 | T1180553 Gear output | Gear output 3rd | 1 | $123.56 | Available to order | 1 |
| 23 | T1180555 Gear output | Gear output 5th | 1 | $139.55 | Obsolete | View Details |
| 24 | T1180531 Gear output | Gear output 1st | 1 | $171.60 | Obsolete | View Details |
| 25 | 1180130-T0301 Bearing sleeve | Bearing sleeve | 1 | $96.75 | Obsolete | View Details |
| 26 | T3800300 Snap Ring, Ext, 62 x 1.7 | Snap Ring, Ext, 62 x 1.7 | 1 | $3.59 | Available to order | 1 |
| 27 | T3800196 Retaining Ring, Bearing | Retaining Ring, Bearing | 1 | $4.92 | Available to order | 1 |
| 28 | T3600112 Oil seal | Oil seal | 1 | $11.32 | Available to order | 1 |
| 29 | T1180178 Sprocket gearbox 17 teeth | Sprocket gearbox 17 teeth 17 Teeth | 1 | $93.05 | Backorder — Late August 2026 | 1 |
| 30 | T1180181 Washer, Gearbox Sprocket | Washer, Gearbox Sprocket | 1 | $7.56 | Available to order | 1 |
| 31 | T1180175 Nut, Gearbox Sprocket | Nut, Gearbox Sprocket | 1 | $5.56 | Available to order | 1 |
