Crankcase
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1160347 Kit crankcase | Kit crankcase » ENG NO 127486 | 1 | $5245.95 | Out of Stock | Notify Me |
| 1 | T1160518 Crankcase | Crankcase ENG NO 127487 » | 1 | $4629.61 | Obsolete | View Details |
| 2 | T3000103 Dowel, Hollow, 12 x 14 | Dowel, Hollow, 12 x 14 | 3 | $4.08 | Available to order | 3 |
| 3 | T3600143 O Ring, ID 9.1 x 1.6, Viton | O Ring, ID 9.1 x 1.6, Viton | 1 | $2.10 | Available to order | 1 |
| 4 | T3550542 Washer, Cu, OD12.5 x Id6.4 | Washer, Cu, OD12.5 x Id6.4 | 5 | $1.05 | Available to order | 5 |
| 5 | T1210242 Bolt, Banjo, M6 x 20 | Bolt, Banjo, M6 x 20 | 2 | $11.03 | Available to order | 2 |
| 6 | T3000101 Dowel, Hollow, 8 x 14 | Dowel, Hollow, 8 x 14 | 2 | $3.90 | Available to order | 2 |
| 7 | T1160360 Oil Deflector Plate | Oil Deflector Plate | 1 | $6.67 | Obsolete | View Details |
| 8 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.40 | Available to order | 2 |
| 9 | T3203115 Bolt, RHHF, M6x1.0x12, S/S | Bolt, RHHF, M6x1.0x12, S/S | 1 | $3.17 | Available to order | 1 |
| 10 | T3450071 Plug | Plug | 1 | $4.87 | Obsolete | View Details |
| 11 | T3550021 Washer | Washer | 1 | $0.64 | Obsolete | View Details |
| 12 | 3800019-T0301 Needle bearing | Needle bearing | 1 | $68.42 | Available to order | 1 |
| 13 | T1210484 Pipe oil feed | Pipe oil feed 3 Cyl | 1 | $25.63 | Obsolete | View Details |
| 14 | T3332704 Screw, Torx, M6 x 14 | Screw, Torx, M6 x 14 M6 x 14mm | 2 | $5.24 | Available to order | 2 |
| 15 | 3550230-T0301 Washer hard | Washer hard | 2 | $3.74 | Obsolete | View Details |
| 16 | T1160620 Sight glass | Sight glass | 1 | $28.50 | Available to order | 1 |
| 17 | T3550085 Washer | Washer | 1 | $3.54 | Obsolete | View Details |
