Seat - Explore
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2317917 Seat Unit, Padded, 580Mm, Blk | Seat Unit, Padded, 580Mm, Blk | 1 | $90.03 | Available to order | 1 |
| 2 | TOS30003 Bolt, M6X16Mm, Flgd, 10.9, Blk | Bolt, M6X16Mm, Flgd, 10.9, Blk | 5 | $1.91 | Available to order | 5 |
| 3 | T2317914 Seat Unit Trim, Explore, Mldg | Seat Unit Trim, Explore, Mldg | 1 | $24.86 | Available to order | 1 |
| 4 | TOS30022 Edge Clip, Push Fit, Steel | Edge Clip, Push Fit, Steel | 2 | $3.35 | Available to order | 2 |
| 5 | TOS30005 Bolt,M6X16Mm,Cap+Wash,10.9,Blk | Bolt,M6X16Mm,Cap+Wash,10.9,Blk | 4 | $1.24 | Available to order | 4 |
| 6 | T2074198 Subframe, Explore, Fab, Black | Subframe, Explore, Fab, Black | 1 | $64.13 | Available to order | 1 |
| 7 | T2074206 Sguard, Rr, Explore, Mldg, Blk | Sguard, Rr, Explore, Mldg, Blk | 1 | $10.24 | Available to order | 1 |
| 8 | T2317915 Decal, Exp Seat Trim, Rhs, Red | Decal, Exp Seat Trim, Rhs, Red | 1 | $51.22 | Available to order | 1 |
| 9 | T2317916 Decal, Exp Seat Trim, Lhs, Red | Decal, Exp Seat Trim, Lhs, Red | 1 | $51.22 | Available to order | 1 |
| 10 | T2317920 Seat Spreader Plate, Stainless | Seat Spreader Plate, Stainless | 1 | $1.44 | Available to order | 1 |
