Classics Seat Wall
Schematic
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9708592 Bench Seat, Ribbed, Black | Bench Seat, Ribbed, Black | — | $468.65 | Unavailable | View Details |
| 2 | A9708593 Bench Seat, Ribbed, Brown | Bench Seat, Ribbed, Brown | — | $360.50 | Unavailable | View Details |
| 3 | A9708594 Bench Seat, Quilted, Black | Bench Seat, Quilted, Black | — | $468.65 | Unavailable | View Details |
| 4 | A2310002 Quilted Bench Seat Brown | Quilted Bench Seat Brown | — | $484.10 | Unavailable | View Details |
| 5 | A2310737 Seat Assy, Comfort, Brown | Seat Assy, Comfort, Brown | — | $463.50 | Obsolete | View Details |
| 6 | A2310736 Black Seat Assembly, Comfort | Black Seat Assembly, Comfort | — | $463.50 | Obsolete | View Details |
| 7 | A9700428 Seat, Rider, Black, Quilted | Seat, Rider, Black, Quilted | — | $234.00 | Available to order | 1 |
| 8 | A9700429 Seat, Rider, Brown, Quilted | Seat, Rider, Brown, Quilted | — | $234.00 | Available to order | 1 |
| 9 | A9700441 Seat, Rider, Quilted, Brown | Seat, Rider, Quilted, Brown | — | $360.50 | Available to order | 1 |
| 10 | A9701501 Seat, Pillion, Quilted, Brown | Seat, Pillion, Quilted, Brown | — | $234.00 | Available to order | 1 |
