Bodywork Side Panels - Bonneville
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2301234-PG Side Panel LH | Side Panel LH Jet Black > 184931 | 1 | $148.72 | Obsolete | View Details |
| 1 | T2309408-PG Sidepanel, LH Painted | Sidepanel, LH Painted Jet Black 184932 > | 1 | $146.19 | Obsolete | View Details |
| 2 | T2301233-PG Side Panel RH | Side Panel RH * PART NO LONGER AVAILABLE * Jet Black > 184931 | 1 | $178.95 | Obsolete | View Details |
| 2 | T2309405-PG Sidepanel, RH Painted | Sidepanel, RH Painted Jet Black 184932 > | 1 | $152.61 | Obsolete | View Details |
| 3 | T2301861 Decal | Decal | 2 | $27.32 | Obsolete | View Details |
| 4 | T3020121 Grommet, 13 x 1 x 6.2 | Grommet, 13 x 1 x 6.2 > 184931 | 4 | $2.00 | Available to order | 4 |
| 4 | T3020003 Grommet | Grommet 184932 > | 4 | $2.00 | Available to order | 4 |
| 5 | T3335566 Screw, Coin Release, M6 x 20 | Screw, Coin Release, M6 x 20 | 1 | $9.22 | Available to order | 1 |
| 6 | T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5 | Sleeve, Flanged, 6.4 x 10 x 6.5 | 2 | $3.59 | Available to order | 2 |
| 7 | T3020082 Grommet, 18 x 1 x 9 | Grommet, 18 x 1 x 9 > 184931 | 2 | $6.77 | Available to order | 2 |
| 7 | T3020031 Grommet; 11.8 x 2.5 x 10 | Grommet; 11.8 x 2.5 x 10 184932 > | 2 | $3.17 | Available to order | 2 |
