Exhaust System - Rocket III Roadster only
Parts (46)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2208921 Header Assy, Complete | Header Assy, Complete N/A to Rocket x | 1 | $1142.32 | Unavailable | View Details |
| 1 | T2208850 Header Pipe & Cover Assy, Black | Header Pipe & Cover Assy, Black Rocket X Only | 1 | $1142.32 | Available to order | 1 |
| 2 | T3050159 Capscrew, SKT HD, M6 x 20, SS | Capscrew, SKT HD, M6 x 20, SS | 5 | $5.47 | Available to order | 5 |
| 3 | T2208913 Clip, Bracket, Exhaust Cover | Clip, Bracket, Exhaust Cover | 5 | $7.90 | Available to order | 5 |
| 4 | T2209725 Cover, Exhaust Header Outer, Black | Cover, Exhaust Header Outer, Black Rocket X Only | 1 | $126.32 | Available to order | 1 |
| 5 | T3332666 Screw, But/Hd ,Skt, M6 x 1.0 x 12, S/S | Screw, But/Hd ,Skt, M6 x 1.0 x 12, S/S | 2 | $4.58 | Available to order | 2 |
| 6 | T3550961 Washer, M6 | Washer, M6 N/A to Rocket X | 2 | $3.82 | Available to order | 2 |
| 6 | T3550957 Washer. M6 x 13 | Washer. M6 x 13 Rocket X Only | 2 | $2.04 | Available to order | 2 |
| 7 | T3350700 Nut, Flanged Domed, M8 | Nut, Flanged Domed, M8 | 6 | $2.31 | Available to order | 6 |
| 8 | T2200326 Exhaust Pipe Sealing Ring | Exhaust Pipe Sealing Ring | 3 | $7.90 | Available to order | 3 |
| 9 | T2208451 Cover, Header, Primary, Assy | Cover, Header, Primary, Assy N/A to Rocket X | 3 | $91.41 | Available to order | 3 |
| 9 | T2209350 Cover, Header, Primary, Assy, Black | Cover, Header, Primary, Assy, Black Rocket X Only | 3 | $100.74 | Available to order | 3 |
| 10 | T2208449 Isolation Rubber | Isolation Rubber | 3 | $2.71 | Available to order | 3 |
| 13 | T2209300 Exhaust Link Pipe Assy | Exhaust Link Pipe Assy | 1 | $232.51 | Out of Stock | Notify Me |
| 14 | T2209830 Cover Assy, Silencer, RH | Cover Assy, Silencer, RH N/A to Rocket X | 1 | $104.49 | Available to order | 1 |
| 14 | T2209841 Cover Assy, Silencer, RH, Black | Cover Assy, Silencer, RH, Black Rocket X Only | 1 | $164.77 | Available to order | 1 |
| 15 | T2209840 Clip, Silencer Cover, Dia 100 | Clip, Silencer Cover, Dia 100 | 2 | $14.66 | Available to order | 2 |
| 16 | T3050303 Capscrew, SKT HD, M6 x 35, Pltd | Capscrew, SKT HD, M6 x 35, Pltd | 2 | $1.29 | Available to order | 2 |
| 17 | T2209820 Cover Assy, Silencer, LH | Cover Assy, Silencer, LH N/A to Rocket X | 1 | $104.49 | Available to order | 1 |
| 17 | T2209842 Cover Assy, Silencer, LH, Black | Cover Assy, Silencer, LH, Black Rocket X Only | 1 | $164.77 | Available to order | 1 |
| 18 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 1 | $1.84 | Available to order | 1 |
| 19 | T2208430 Exhaust Gasket | Exhaust Gasket | 1 | $24.52 | Available to order | 1 |
| 20 | T2208431 Clamp, Exhaust, ID 53.3 | Clamp, Exhaust, ID 53.3 | 1 | $13.01 | Available to order | 1 |
| 21 | T3205653 Bolt, HHF, Lghtd, M8 x 30, Slv | Bolt, HHF, Lghtd, M8 x 30, Slv | 3 | $1.29 | Available to order | 3 |
| 22 | T2208422 Clamp, Exhaust, ID 47.3 | Clamp, Exhaust, ID 47.3 | 2 | $13.01 | Available to order | 2 |
| 23 | T2208419 Exhaust Gasket | Exhaust Gasket | 2 | $19.54 | Available to order | 2 |
| 24 | T3010235 Flanged Sleeve, M8 | Flanged Sleeve, M8 | 2 | $17.74 | Available to order | 2 |
| 25 | T3020300 Grommet, Dia 19.5 x 4 Panel | Grommet, Dia 19.5 x 4 Panel | 2 | $3.61 | Backorder — Late October 2026 | 2 |
| 26 | T3555033 Washer, 8.4 x 24 x 2 | Washer, 8.4 x 24 x 2 | 2 | $2.91 | Available to order | 2 |
| 27 | T3202319 Bolt, HHF, M8 x 35, Slv | Bolt, HHF, M8 x 35, Slv | 2 | $2.79 | Available to order | 2 |
| 28 | T2209801 Silencer Assy, LH | Silencer Assy, LH All Expt BR - N/A to Rocket X | 1 | $2343.23 | Out of Stock | Notify Me |
| 28 | T2209720 Silencer Assy, LH | Silencer Assy, LH All Expt BR - Rocket X Only | 1 | $3019.23 | Available to order | 1 |
| 28 | T2209981 Silencer Assy, LH, 300 CPSI | Silencer Assy, LH, 300 CPSI BR Only - N/A to Rocket X | 1 | $1251.11 | Out of Stock | Notify Me |
| 28 | T2209661 Silencer Assy, LH, 300 CPSI | Silencer Assy, LH, 300 CPSI BR Only - Rocket X Only | 1 | $915.65 | Out of Stock | Notify Me |
| 29 | T3350301 Nut, Flanged, M8, Silver | Nut, Flanged, M8, Silver | 4 | $0.86 | Available to order | 4 |
| 30 | T2209802 Silencer Assy, RH | Silencer Assy, RH All Expt BR - N/A to Rocket X | 1 | $2343.23 | Available to order | 1 |
| 30 | T2209730 Silencer Assy, RH | Silencer Assy, RH All Expt BR - Rocket X Only | 1 | $3019.23 | Available to order | 1 |
| 30 | T2209982 Silencer Assy, RH,300 CPSI | Silencer Assy, RH,300 CPSI BR Only - N/A to Rocket X | 1 | $1251.11 | Out of Stock | Notify Me |
| 30 | T2209662 Silencer Assy, RH, 300 CPSI | Silencer Assy, RH, 300 CPSI BR Only - Rocket X Only | 1 | $915.65 | Out of Stock | Notify Me |
| 31 | T3205254 Bolt, HHF, Lghtd, M8 x 20, Slv | Bolt, HHF, Lghtd, M8 x 20, Slv | 4 | $1.73 | Available to order | 4 |
| 32 | T3550276 Washer, M8, Hardened | Washer, M8, Hardened | 4 | $1.04 | Available to order | 4 |
| 33 | T2209130 Cover, Header Casting, Chromed | Cover, Header Casting, Chromed N/A to Rocket X | 3 | $94.42 | Available to order | 3 |
| 33 | T2209325 Cover, Header, Casting, Black | Cover, Header, Casting, Black Rocket X Only | 3 | $92.37 | Available to order | 3 |
| 34 | T2209810 Bracket, Silencer, LH | Bracket, Silencer, LH | 1 | $26.60 | Available to order | 1 |
| 35 | T2209815 Bracket, Silencer, RH | Bracket, Silencer, RH | 1 | $26.60 | Available to order | 1 |
| 36 | T3202325 Bolt, HHF, M8 x 43, Slv | Bolt, HHF, M8 x 43, Slv | 2 | $1.73 | Available to order | 2 |
