F. Footrests & Mountings - Rocket III Classic (incl. Special Edition)
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2083008 Foot Control Mtg Assy, LH | Foot Control Mtg Assy, LH PART NO LONGER AVAILABLE | 1 | $233.89 | Obsolete | View Details |
| 2 | T2083010 Foot Control Mtg Assy, RH | Foot Control Mtg Assy, RH PART NO LONGER AVAILABLE | 1 | $251.71 | Obsolete | View Details |
| 3 | T3205254 Bolt, HHF, Lghtd, M8 x 20, Slv | Bolt, HHF, Lghtd, M8 x 20, Slv | 10 | $1.73 | Available to order | 10 |
| 4 | T2083000 Footboard, Die Cast, LH | Footboard, Die Cast, LH | 1 | $159.27 | Out of Stock | Notify Me |
| 5 | T2083001 Footboard, Die Cast, RH | Footboard, Die Cast, RH PART NO LONGER AVAILABLE | 1 | $154.63 | Obsolete | View Details |
| 6 | T2083006 Rubber, Footboard | Rubber, Footboard | 2 | $74.63 | Available to order | 2 |
| 7 | T2083017 Pivot Pin | Pivot Pin | 2 | $18.42 | Available to order | 2 |
| 8 | T2083068 Spring, Footboard, Return | Spring, Footboard, Return | 2 | $6.81 | Available to order | 2 |
| 9 | T3500207 Circlip, Ext 8 X 0.89 | Circlip, Ext 8 X 0.89 | 2 | $3.04 | Available to order | 2 |
| 10 | T2085164 Peg, Bank Angle, 9.2mm | Peg, Bank Angle, 9.2mm | 2 | $14.59 | Available to order | 2 |
| 11 | T2081455 Heel Plate, RH | Heel Plate, RH | 1 | $113.51 | Available to order | 1 |
| 12 | T3203115 Bolt, RHHF, M6x1.0x12, S/S | Bolt, RHHF, M6x1.0x12, S/S | 2 | $3.37 | Available to order | 2 |
| 13 | T2083014 Cover, Brake Reservoir | Cover, Brake Reservoir | 1 | $29.49 | Available to order | 1 |
| 14 | T3350088 Domenut, Locking, M6 | Domenut, Locking, M6 | 2 | $1.91 | Available to order | 2 |
