Transmission Damper & Drive Shaft
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1270800 Shaft Assy, Transmission Damper | Shaft Assy, Transmission Damper | 1 | $739.35 | Available to order | 1 |
| 2 | T1270870 Circlip | Circlip | 1 | $4.36 | Out of Stock | Notify Me |
| 3 | T1270865 Cap, Collet | Cap, Collet | 1 | $4.30 | Available to order | 1 |
| 4 | T1270898 Collets | Collets | 2 | $7.52 | Available to order | 2 |
| 5 | T1270850 Bearing, Torsional Damper | Bearing, Torsional Damper | 1 | $36.81 | Available to order | 1 |
| 6 | T1277777 BUSH, GEAR | BUSH, GEAR | 1 | $44.27 | Out of Stock | Notify Me |
| 7 | T1270821 Gear, Damper, 48T, Helical | Gear, Damper, 48T, Helical | 1 | $167.31 | Available to order | 1 |
| 8 | T1271845 Washer | Washer | 1 | $12.07 | Unavailable | View Details |
| 9 | T1270840 Follower, Torsional Damper | Follower, Torsional Damper | 1 | $82.03 | Obsolete | View Details |
| 10 | T1270888 Spring, Torsional Damper | Spring, Torsional Damper | 1 | $21.51 | Out of Stock | Notify Me |
| 11 | T1270815 Shaft, Damper, Threaded, M32 | Shaft, Damper, Threaded, M32 | 1 | $292.22 | Backorder — Late August 2026 | 1 |
| 12 | T3801135 Bearing, Ball, 45 x 75 x 16 | Bearing, Ball, 45 x 75 x 16 | 1 | $57.98 | Available to order | 1 |
| 13 | T1270886 Washer, Spring, Disc | Washer, Spring, Disc | 1 | $2.74 | Available to order | 1 |
| 14 | T1271111 Nut, Seal, Output, M32 | Nut, Seal, Output, M32 | 1 | $16.66 | Available to order | 1 |
| 15 | T1270700 Shaft/Universal Joint | Shaft/Universal Joint | 1 | $475.29 | Available to order | 1 |
| 16 | T1270500 Spring, Drive Shaft | Spring, Drive Shaft | 1 | $4.92 | Available to order | 1 |
