Front Mudguard
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 56TA6JAZ Front Mudguard | Front Mudguard Matt Silver | 1 | $95.87 | Available to order | 1 |
| 3 | TA181429 Bracket, Brace, Mudguard, LH | Bracket, Brace, Mudguard, LH | 1 | $14.30 | Available to order | 1 |
| 4 | TA181430 Bracket, Brace, Mudguard, RH | Bracket, Brace, Mudguard, RH | 1 | $14.30 | Available to order | 1 |
| 5 | TA181417 Fork Protector, LH | Fork Protector, LH | 1 | $9.41 | Available to order | 1 |
| 6 | TA181418 Fork Protector, RH | Fork Protector, RH | 1 | $9.41 | Available to order | 1 |
| 7 | LBU00187 Screw, Btn Hd, Step, M6 x 1 | Screw, Btn Hd, Step, M6 x 1 | 2 | $1.45 | Available to order | 2 |
| 8 | 56TA24BF Brace, Mudguard, LH, Matt Phantom Blk | Brace, Mudguard, LH, Matt Phantom Blk | 1 | $29.62 | Available to order | 1 |
| 9 | 56TA25BF Brace, Mudguard, RH, Matt Phantom Blk | Brace, Mudguard, RH, Matt Phantom Blk | 1 | $28.62 | Available to order | 1 |
| 10 | LBU00188 Screw, Btn Hd Step, M6 x 1 | Screw, Btn Hd Step, M6 x 1 | 2 | $1.21 | Available to order | 2 |
| 11 | LBU00189 Screw, Btn Hd, Step, M6 x 1 | Screw, Btn Hd, Step, M6 x 1 | 2 | $0.71 | Available to order | 2 |
| 13 | LBU00177 Screw, Btn Hd, M5 x 0.8 | Screw, Btn Hd, M5 x 0.8 | 6 | $0.71 | Available to order | 6 |
| 14 | TA181402 Brace, Mudguard | Brace, Mudguard | 1 | $10.22 | Available to order | 1 |
| 15 | JY181284 Nylon Washer | Nylon Washer | 2 | $0.18 | Available to order | 2 |
| 16 | JG181374 Nut, Square, M5 | Nut, Square, M5 | 2 | $0.10 | Available to order | 2 |
