Camshaft & Camdrive
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TA511206 Camshaft Assy, Intake | Camshaft Assy, Intake | 1 | $289.34 | Available to order | 1 |
| 2 | TA511208 Camshaft Assy, Exhaust | Camshaft Assy, Exhaust | 1 | $305.30 | Available to order | 1 |
| 3 | TA511226 Sprocket, Camshaft | Sprocket, Camshaft | 2 | $25.26 | Backorder — Mid August 2026 | 2 |
| 4 | LAC00144 Bolt, Socket, Step, M10 x 1 | Bolt, Socket, Step, M10 x 1 | 2 | $4.86 | Available to order | 2 |
| 11 | LAE00022 Bolt, flgd, M6 x 1 | Bolt, flgd, M6 x 1 | 1 | $0.66 | Available to order | 1 |
| 12 | LDB00182 Plain Washer | Plain Washer | 1 | $0.10 | Available to order | 1 |
| 13 | KAEW0620 Bolt, Flanged, M6 x 1 | Bolt, Flanged, M6 x 1 | 1 | $0.34 | Available to order | 1 |
| 14 | TA511237 Tensioner Chain | Tensioner Chain | 1 | $26.36 | Available to order | 1 |
| 15 | CS101128 Gasket | Gasket | 1 | $0.46 | Available to order | 1 |
| 16 | TA541024 Guide Chain | Guide Chain | 1 | $14.60 | Available to order | 1 |
| 17 | DH101392 Bolt, Socket, M6 x 1 | Bolt, Socket, M6 x 1 | 1 | $1.58 | Available to order | 1 |
| 18 | TA511212 Chain Timing | Chain Timing | 1 | $121.14 | Available to order | 1 |
| 19 | TA511231 Guide Chain, Tight Side | Guide Chain, Tight Side | 1 | $11.53 | Available to order | 1 |
