Front Wheel
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 52TA0640 Front Wheel Assy, Scrambler 400, W/O Tyre | Front Wheel Assy, Scrambler 400, W/O Tyre | 1 | $623.02 | Available to order | 1 |
| 2 | TA131012 Spindle | Spindle | 1 | $63.46 | Available to order | 1 |
| 3 | TA131017 Collar | Collar | 2 | $4.74 | Available to order | 2 |
| 4 | 39162619 Oil Seal, 25 x 4 x 5 | Oil Seal, 25 x 4 x 5 | 2 | $1.58 | Available to order | 2 |
| 5 | KPBC6203 Bearing Ball | Bearing Ball | 2 | $17.90 | Available to order | 2 |
| 6 | TA131008 Spacer | Spacer | 1 | $34.58 | Available to order | 1 |
| 7 | KEBB4017 Circlip Internal | Circlip Internal | 1 | $1.24 | Available to order | 1 |
| 9 | DK151026 Valve, Tubeless Tyre | Valve, Tubeless Tyre | 1 | $2.25 | Available to order | 1 |
