Clutch
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TA551402 Housing Assembly, Clutch | Housing Assembly, Clutch | 1 | $254.09 | Available to order | 1 |
| 2 | YTA04026 Hub, Clutch | Hub, Clutch | 1 | $84.79 | Available to order | 1 |
| 3 | JY551442 Spring, Seat, Judder | Spring, Seat, Judder | 1 | $8.88 | Available to order | 1 |
| 4 | JY551441 Spring, Judder | Spring, Judder | 1 | $13.39 | Available to order | 1 |
| 5 | TA551408 Collar | Collar | 1 | $13.82 | Available to order | 1 |
| 6 | JY551403 Clutch Washer | Clutch Washer | 1 | $1.36 | Available to order | 1 |
| 7 | JY551019 Washer, Plain | Washer, Plain | 1 | $0.79 | Available to order | 1 |
| 8 | DG101275 Conical Washer | Conical Washer | 1 | $0.91 | Available to order | 1 |
| 9 | LCG00009 Nut, Hex Flgd, M16 x 1.5, LH | Nut, Hex Flgd, M16 x 1.5, LH | 1 | $4.64 | Available to order | 1 |
| 10 | 36TA0083 Friction Kit, Clutch | Friction Kit, Clutch | 1 | $201.67 | Available to order | 1 |
| 11 | JY551437 Clutch Plate B | Clutch Plate B | 1 | $8.01 | Available to order | 1 |
| 12 | JY551436 Clutch Plate A | Clutch Plate A | 5 | $8.24 | Available to order | 5 |
| 15 | YTA04027 Clutch Wheel | Clutch Wheel | 1 | $41.27 | Available to order | 1 |
| 16 | TA551415 Holder, Ball, Clutch | Holder, Ball, Clutch | 1 | $6.58 | Available to order | 1 |
| 17 | KMAA1500 Ball Steel | Ball Steel | 1 | $0.57 | Available to order | 1 |
| 18 | JY551443 Stopper Plate | Stopper Plate | 1 | $7.80 | Available to order | 1 |
| 19 | YTA04006 Clutch Spring | Clutch Spring | 3 | $14.23 | Available to order | 3 |
| 20 | LAD00166 Bolt, Flgd, M6 x 1 x L35 x CL 8.8 x Brt | Bolt, Flgd, M6 x 1 x L35 x CL 8.8 x Brt | 3 | $1.24 | Available to order | 3 |
| 21 | JY551440 Seat Spring | Seat Spring | 3 | $7.80 | Available to order | 3 |
| 22 | TA551006 Shaft, Clutch | Shaft, Clutch | 1 | $21.22 | Available to order | 1 |
| 23 | TA541226 Torsion Spring | Torsion Spring | 1 | $1.36 | Available to order | 1 |
| 24 | LDB00020 Washer, 12.5 x 24 x 0.8T | Washer, 12.5 x 24 x 0.8T | 1 | $0.22 | Available to order | 1 |
| 25 | TA561208 Oil Seal | Oil Seal | 1 | $1.24 | Available to order | 1 |
| 26 | TA541228 Bearing, Needle | Bearing, Needle | 1 | $5.93 | Available to order | 1 |
| 27 | TA541049 Bearing, Needle | Bearing, Needle | 1 | $3.70 | Backorder — Mid August 2026 | 1 |
| 28 | TA541046 Spacer | Spacer | 1 | $0.41 | Available to order | 1 |
| 29 | TA551411 Shaft, Push | Shaft, Push | 1 | $24.83 | Available to order | 1 |
