Airbox
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2201403 Airbox Assembly | Airbox Assembly | 1 | $277.73 | Obsolete | View Details |
| 2 | T2204014 Seal | Seal | 1 | $17.86 | Obsolete | View Details |
| 3 | T3330129 Screw | Screw M5 x 15mm | 12 | $0.42 | Obsolete | View Details |
| 4 | T2204007 Hose intake | Hose intake | 2 | $37.00 | Obsolete | View Details |
| 5 | T2201490 Intake trumpet | Intake trumpet | 2 | $30.95 | Obsolete | View Details |
| 6 | T2200162 Duct intake | Duct intake | 2 | $34.73 | Obsolete | View Details |
| 7 | T2204001 Filter, Airbox | Filter, Airbox | 1 | $42.75 | Available to order | 1 |
| 7 | T2204015 Air Filter, Multipack (5) | Air Filter, Multipack (5) | 1 | $130.05 | Obsolete | View Details |
| 8 | T2204002 Filter housing | Filter housing | 1 | $24.91 | Obsolete | View Details |
| 9 | T3331043 Screw, Pan/Hd, Tx, M6 x 12, Slv | Screw, Pan/Hd, Tx, M6 x 12, Slv | 4 | $0.97 | Available to order | 4 |
| 10 | T3700066 Hose Clip, 22.7-27.5mm | Hose Clip, 22.7-27.5mm » 162141 | 1 | $16.83 | Available to order | 1 |
| 10 | T3700081 Clip hose | Clip hose 162142 » | 1 | $1.62 | Available to order | 1 |
| 11 | T2204003 Pipe breather | Pipe breather » 162141 | 1 | $18.31 | Obsolete | View Details |
| 11 | T2204021 Breather pipe | Breather pipe 162142 » | 1 | $21.57 | Available to order | 1 |
| 12 | T3620239 Pipe, Airbox Drain | Pipe, Airbox Drain | 1 | $11.56 | Available to order | 1 |
| 13 | T3700030 Clip pipe | Clip pipe > 162141 | 1 | $0.97 | Available to order | 1 |
| 14 | T3450145 End Tip | End Tip | 1 | $1.21 | Available to order | 1 |
| 15 | T1241062 Housing | Housing | 1 | $52.75 | Obsolete | View Details |
| 16 | T1240888 Stepper motor | Stepper motor ** PART NO LONGER AVAILABLE ** | 1 | $145.81 | Obsolete | View Details |
| 17 | T2204005 Pipe by-pass | Pipe by-pass » 162141 | 1 | $21.86 | Out of Stock | Notify Me |
| 17 | T2204023 Pipe by-pass | Pipe by-pass 162142 » | 1 | $16.04 | Obsolete | View Details |
| 18 | T3330728 Screw, Pan/Hd, Tx, M5 x 16, Enc | Screw, Pan/Hd, Tx, M5 x 16, Enc | 2 | $0.97 | Available to order | 2 |
| 19 | T3600037 O ring | O ring | 1 | $1.51 | Available to order | 1 |
| 20 | T2204009 Bracket | Bracket | 1 | $3.70 | Obsolete | View Details |
| 21 | T2204026 Air inlet | Air inlet RH | 1 | $27.63 | Obsolete | View Details |
| 22 | T2204025 Air inlet | Air inlet LH | 1 | $27.63 | Obsolete | View Details |
| 23 | T2201295 Spring sealing | Spring sealing | 4 | $1.79 | Available to order | 4 |
| 24 | T1242523 Tube assembly | Tube assembly | 1 | $17.15 | Obsolete | View Details |
| 25 | T2204020 Gasket | Gasket | 1 | $13.99 | Obsolete | View Details |
| 27 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 1 | $1.40 | Available to order | 1 |
| 28 | T3555017 Washer, 6.5 x 12.5 x 0.8 | Washer, 6.5 x 12.5 x 0.8 M6 Hardened | 1 | $3.04 | Available to order | 1 |
| 29 | T2501740 Battery Strap | Battery Strap | 1 | $9.97 | Available to order | 1 |
| 30 | T3700171 Hose Clip, Dia 14.0 | Hose Clip, Dia 14.0 | 1 | $6.94 | Backorder — Early August 2026 | 1 |
| 31 | T3450127 Bung | Bung | 1 | $1.14 | Obsolete | View Details |
| 32 | T3660113 Rubber pad | Rubber pad | 2 | $1.35 | Obsolete | View Details |
| 34 | T3450149 Bung | Bung | 1 | $5.54 | Obsolete | View Details |
