Handlebars and Switches
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2040312 Handlebars | Handlebars LH Black | 1 | $122.76 | Obsolete | View Details |
| 2 | T2040313 Handlebars | Handlebars RH Black | 1 | $122.76 | Obsolete | View Details |
| 3 | T3050130 Capscrew, M8 x 40 | Capscrew, M8 x 40 M8 x 40mm | 2 | $7.62 | Available to order | 2 |
| 4 | T3050334 Screw, Cap/Hd, M6 x 20, Slv | Screw, Cap/Hd, M6 x 20, Slv M6 x 20mm | 2 | $1.51 | Available to order | 2 |
| 5 | T2040094 Switch assembly | Switch assembly LH All Markets Except CA,US,MY,JP » 171872 SG, 110500 » 171872 | 1 | $92.98 | Obsolete | View Details |
| 5 | T2040112 Switch assembly | Switch assembly CA,US,MY & JP > 228984 SG > 110499 All Markets Except CA,US,MY & JP 171873 > 228984 | 1 | $176.33 | Obsolete | View Details |
| 5 | T2040274 Switch Assy, Lights On, LH | Switch Assy, Lights On, LH 228985 > | 1 | $220.55 | Available to order | 1 |
| 6 | T2040096 Switch Assy, Rh | Switch Assy, Rh RH | 1 | $184.39 | Available to order | 1 |
| 7 | T3331810 Screw, M5 X 40 | Screw, M5 X 40 M5 x 40mm | 1 | $0.72 | Obsolete | View Details |
| 8 | T3331790 Screw, Pan/Hd, Ph, M5 x 30, Blk | Screw, Pan/Hd, Ph, M5 x 30, Blk M5 x 30mm | 1 | $0.89 | Available to order | 1 |
| 9 | T3331800 Screw, M5 X 22 | Screw, M5 X 22 M5 x 22mm | 2 | $1.21 | Available to order | 2 |
| 10 | T2040231 Actuator assembly | Actuator assembly PART NO LONGER AVAILABLE | 1 | $54.41 | Obsolete | View Details |
| 11 | T2040740 Handlebar Grip, LH | Handlebar Grip, LH LH | 1 | $18.16 | Available to order | 1 |
| 12 | T2040750 Grip | Grip RH; includes throttle tube | 1 | $18.16 | Available to order | 1 |
| 13 | T2040209 Bar end weights | Bar end weights | 2 | $35.64 | Available to order | 2 |
| 14 | T3330643 Screw, M5 x 30, CSK SKT, Patch | Screw, M5 x 30, CSK SKT, Patch | 2 | $2.00 | Available to order | 2 |
| 15 | T2040451 Throttle cable | Throttle cable | 1 | $50.28 | Available to order | 1 |
| 16 | T1240941 Clip | Clip | 1 | $15.40 | Available to order | 1 |
| 17 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long Switch cube harnesses to main & headlight harnesses | 1 | $0.89 | Available to order | 1 |
