Swinging Arm
Parts (35)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2055212 Swinging Arm Assy, Slv | Swinging Arm Assy, Slv Includes bearings - items 7, 8, 10, 11, 13 & 14 | 1 | $1031.12 | Obsolete | View Details |
| 1 | T2055214 Swinging Arm | Swinging Arm Includes bearings Black Special edition - items 7, 8, 10, 11, 13 & 14 | 1 | $2023.24 | Obsolete | View Details |
| 2 | T2057351 Spindle, Swing Arm | Spindle, Swing Arm PART NO LONGER AVAILABLE | 1 | $96.95 | Obsolete | View Details |
| 3 | T2001078 Bolt, Front Spindle, Slv | Bolt, Front Spindle, Slv » 144713 | 2 | $20.19 | Out of Stock | Notify Me |
| 4 | T3900092 Label, Chain & Tyres | Label, Chain & Tyres | 1 | $6.06 | Available to order | 1 |
| 5 | T2079698 Lock Ring, M36 | Lock Ring, M36 | 1 | $24.64 | Obsolete | View Details |
| 6 | T2079697 Adjuster Collar, M36 | Adjuster Collar, M36 | 1 | $21.20 | Obsolete | View Details |
| 7 | T3600041 Seal, Oil | Seal, Oil | 1 | $9.09 | Available to order | 1 |
| 8 | T3500203 Circlip, Int, 52 x 2 | Circlip, Int, 52 x 2 | 1 | $16.64 | Available to order | 1 |
| 9 | T2057347 Spacer, S/arm, Anodised | Spacer, S/arm, Anodised | 1 | $7.18 | Out of Stock | Notify Me |
| 10 | T3800029 Bearing Ball, 25 52 15 | Bearing Ball, 25 52 15 | 1 | $16.91 | Available to order | 1 |
| 11 | T3600029 Seal, Oil | Seal, Oil | 2 | $6.37 | Available to order | 2 |
| 12 | T2057389 Sleeve, S/Arm, Dia 30 x 39LG | Sleeve, S/Arm, Dia 30 x 39LG * Part No Longer Available * | 1 | $15.16 | Obsolete | View Details |
| 13 | T3800028 Bearing, Needle Roller | Bearing, Needle Roller | 1 | $15.12 | Out of Stock | Notify Me |
| 14 | T2057340 Spacer, Tube | Spacer, Tube | 1 | $16.51 | Obsolete | View Details |
| 15 | T3331730 Bolt, HHF, M14 x 1.5 x 40, Slv | Bolt, HHF, M14 x 1.5 x 40, Slv | 1 | $26.40 | Available to order | 1 |
| 16 | T3550339 Washer, M14 | Washer, M14 | 1 | $3.45 | Available to order | 1 |
| 17 | T2057363 Chainguard | Chainguard | 1 | $30.23 | Available to order | 1 |
| 18 | T2057359 Hose Guide | Hose Guide 187892 > ** PART NO LONGER AVAILABLE ** | 1 | $2.71 | Obsolete | View Details |
| 18 | T2057361 Hose Guide | Hose Guide >187891 | 1 | $5.06 | Obsolete | View Details |
| 19 | T3331043 Screw, Pan/Hd, Tx, M6 x 12, Slv | Screw, Pan/Hd, Tx, M6 x 12, Slv | 2 | $1.04 | Available to order | 2 |
| 20 | T2057362 Chainguard, Lower | Chainguard, Lower | 1 | $24.35 | Available to order | 1 |
| 21 | T2057365 Chain Rubbing Strip | Chain Rubbing Strip | 1 | $37.43 | Available to order | 1 |
| 22 | T3331517 Screw, P/HD Tx, Shld, M6 x 16, S | Screw, P/HD Tx, Shld, M6 x 16, S | 4 | $1.04 | Available to order | 4 |
| 23 | T3330706 Bolt, Rhhf, Lightened, M6 X 18 | Bolt, Rhhf, Lightened, M6 X 18 M6 x 16mm | 1 | $1.94 | Obsolete | View Details |
| 24 | T2050175 Grommet | Grommet | 1 | $6.70 | Out of Stock | Notify Me |
| 25 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv No longer required | 1 | $2.79 | Available to order | 1 |
| 26 | T3700020 P Clip | P Clip No longer required | 2 | $12.22 | Out of Stock | Notify Me |
| 27 | T3350012 Locknut, Flgd, M6, Black, Zinc | Locknut, Flgd, M6, Black, Zinc No longer required | 1 | $1.21 | Available to order | 1 |
| 28 | T3450009 Plug, M6 | Plug, M6 | 1 | $3.45 | Available to order | 1 |
| 29 | T3050120 Stud, Caliper Carrier | Stud, Caliper Carrier | 1 | $6.22 | Obsolete | View Details |
| 30 | T3010062 Flanged Sleeve, M6 x 7.8 x 2.85 | Flanged Sleeve, M6 x 7.8 x 2.85 | 1 | $7.60 | Available to order | 1 |
| 31 | T3550058 Washer | Washer » 144713 | 1 | $3.55 | Obsolete | View Details |
| 32 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 1 | $3.73 | Available to order | 1 |
| 34 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 1 | $1.50 | Available to order | 1 |
