Crankcase Fixings
Parts (7)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T3330040 Screw | Screw M8 x 65mm | 2 | $2.99 | Obsolete | View Details |
| 2 | 3330043-T0301 Screw, Torx | Screw, Torx » 19781 M8 x 130mm | 1 | $0.57 | Out of Stock | Notify Me |
| 2 | T3330044 Screw, Torx, Pan/Hd, M8 x 155, Black | Screw, Torx, Pan/Hd, M8 x 155, Black 19782 » M8 x 155mm | 1 | $20.46 | Available to order | 1 |
| 3 | T3330121 Screw, Torx | Screw, Torx PART NO LONGER AVAILABLE - M8 x 105mm | 6 | $1.70 | Obsolete | View Details |
| 4 | 3330021-T0301 Screw, Torx | Screw, Torx M8 x 80mm | 4 | $5.60 | Available to order | 4 |
| 5 | T3331299 Screw, Pan/HD, Tx, M6 x 40, Slv | Screw, Pan/HD, Tx, M6 x 40, Slv | 6 | $3.70 | Available to order | 6 |
| 7 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 5 | $1.06 | Available to order | 5 |
