Exhaust System >281465 ALL expt AU,NZ,ZA - > 333178 AU,NZ,ZA
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2204731 Header Assembly, Pre Cat | Header Assembly, Pre Cat All except AU, HK, NZ, ZA | 1 | $1056.22 | Out of Stock | Notify Me |
| 1 | T2204732 Header Assembly, Non Cat | Header Assembly, Non Cat AU, HK, NZ, ZA | 1 | $1073.83 | Out of Stock | Notify Me |
| 2 | T2206078 Clamp, Exhaust, Dia 52-54mm | Clamp, Exhaust, Dia 52-54mm | 1 | $20.89 | Available to order | 1 |
| 3 | T2202115 Gasket, Exhaust Header | Gasket, Exhaust Header | 1 | $12.98 | Available to order | 1 |
| 4 | T3205653 Bolt, HHF, Lghtd, M8 x 30, Slv | Bolt, HHF, Lghtd, M8 x 30, Slv | 1 | $1.21 | Available to order | 1 |
| 5 | T2200337 Exhaust, Secondary Assembly | Exhaust, Secondary Assembly > 281465 | 1 | $275.32 | Out of Stock | Notify Me |
| 5 | T2200324 Exhaust, Secondary Assembly | Exhaust, Secondary Assembly 281466 > | 1 | $252.55 | Obsolete | View Details |
| 6 | T2200331 Gasket, Exhaust | Gasket, Exhaust | 2 | $8.03 | Available to order | 2 |
| 7 | T2200431 Cover Assy, Silencer Clamp, RH | Cover Assy, Silencer Clamp, RH | 1 | $165.03 | Obsolete | View Details |
| 8 | T2200435 Cover Assy, Silencer Clamp, LH | Cover Assy, Silencer Clamp, LH PART NO LONGER AVAILABLE | 1 | $165.03 | Obsolete | View Details |
| 9 | T2200348 Silencer, Oval, Rhs, Cat | Silencer, Oval, Rhs, Cat All except AU, HK, NZ, ZA | 1 | $774.57 | Out of Stock | Notify Me |
| 9 | T2200352 Silencer, Oval, Rhs | Silencer, Oval, Rhs AU, HK, NZ, ZA | 1 | $774.57 | Out of Stock | Notify Me |
| 10 | T2200349 Silencer, Oval, Lhs, Cat | Silencer, Oval, Lhs, Cat All except AU, HK, NZ, ZA | 1 | $774.57 | Out of Stock | Notify Me |
| 10 | T2200353 Silencer, Oval, Lhs | Silencer, Oval, Lhs AU, HK, NZ, ZA | 1 | $643.72 | Obsolete | View Details |
| 11 | T2200237 Pressing, Heat Shield, Rh | Pressing, Heat Shield, Rh | 1 | $83.67 | Available to order | 1 |
| 12 | T2200235 Pressing, Heat Shield, Lh | Pressing, Heat Shield, Lh | 1 | $83.67 | Available to order | 1 |
| 13 | T3331625 Screw, Btn Hd, M8 x 12, Slv | Screw, Btn Hd, M8 x 12, Slv | 4 | $1.72 | Available to order | 4 |
| 14 | T3205109 Bolt, HHF, Lghtd, M8 x 45, Slv | Bolt, HHF, Lghtd, M8 x 45, Slv | 2 | $5.12 | Available to order | 2 |
| 15 | T2200622 Bush, Rubber, M8 | Bush, Rubber, M8 | 6 | $2.25 | Available to order | 6 |
| 16 | T3010705 Flanged Sleeve, 8.4 x 12.4 x 13.8 | Flanged Sleeve, 8.4 x 12.4 x 13.8 | 6 | $10.44 | Available to order | 6 |
| 17 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 3 | $2.45 | Available to order | 3 |
| 18 | T2201347 Sensor, Oxygen, Heated | Sensor, Oxygen, Heated > 281465 | 1 | $254.75 | Out of Stock | Notify Me |
| 18 | T2204191 Oxygen Sensor Spares Kit | Oxygen Sensor Spares Kit 281466 > | 1 | $219.06 | Available to order | 1 |
| 19 | T2200326 Exhaust Pipe Sealing Ring | Exhaust Pipe Sealing Ring | 3 | $7.42 | Available to order | 3 |
| 20 | T3350301 Nut, Flanged, M8, Silver | Nut, Flanged, M8, Silver | 6 | $0.81 | Available to order | 6 |
| 21 | T2206075 Clamp, Exhaust, Dia 43-47mm | Clamp, Exhaust, Dia 43-47mm | 2 | $11.03 | Available to order | 2 |
| 22 | T3202307 Bolt, HHF, M8 x 50, Slv | Bolt, HHF, M8 x 50, Slv | 1 | $6.65 | Available to order | 1 |
| 23 | T3450094 Grommet, Heat Resisting | Grommet, Heat Resisting - Part No Longer Available | 1 | $3.66 | Obsolete | View Details |
| 24 | T3550277 Washer, M8 | Washer, M8 | 4 | $1.06 | Available to order | 4 |
