Seat
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2318014 Rider Seat | Rider Seat | 1 | $331.75 | Available to order | 1 |
| 2 | T2317015 Pillion Seat | Pillion Seat | 1 | $236.30 | Available to order | 1 |
| 3 | T3330858 Bolt, But/Hd, M6 x 15, Shld, Slv | Bolt, But/Hd, M6 x 15, Shld, Slv | 2 | $2.55 | Available to order | 2 |
| 4 | T3331047 Screw, Pan/Hd, TX, M6 x 25, Slv | Screw, Pan/Hd, TX, M6 x 25, Slv | 1 | $4.05 | Available to order | 1 |
| 5 | T2314101 Cap, Pillion Seat | Cap, Pillion Seat | 1 | $4.86 | Available to order | 1 |
| 6 | T2317050-PG Seat Cowl, Jet Black | Seat Cowl, Jet Black Black Bikes | 1 | $367.20 | Backorder — Late August 2026 | 1 |
| 6 | T2317050-LE Seat Cowl, Granite | Seat Cowl, Granite Granite/Red Bikes & Granite/Yellow Bikes | 1 | $367.20 | Available to order | 1 |
| 7 | T2317093 Spacer, Seat Cowl | Spacer, Seat Cowl | 1 | $8.62 | Available to order | 1 |
| 8 | T2307368 Rubber Foot, Seat | Rubber Foot, Seat | 4 | $3.70 | Available to order | 4 |
| 9 | T3331436 Screw, S/Tap, Pan, Torx, 4 x 11, PT | Screw, S/Tap, Pan, Torx, 4 x 11, PT | 4 | $0.75 | Available to order | 4 |
| 10 | T3330454 Screw, Csk, M6 x 30, T30, Blk | Screw, Csk, M6 x 30, T30, Blk | 1 | $4.32 | Available to order | 1 |
