Airbox
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2204362 Airbox Assy, Single Throttle | Airbox Assy, Single Throttle | 1 | $275.75 | Backorder — Mid August 2026 | 1 |
| 2 | T2201122 Air Filter | Air Filter | 1 | $36.54 | Available to order | 1 |
| 3 | T2204578 Seal, Filter Face | Seal, Filter Face | 1 | $8.88 | Out of Stock | Notify Me |
| 4 | T2201129 Casette, Air Filter | Casette, Air Filter | 1 | $32.54 | Out of Stock | Notify Me |
| 5 | T3332464 Screw, S/Tap, Tx, 5 x 25 | Screw, S/Tap, Tx, 5 x 25 | 4 | $2.17 | Available to order | 4 |
| 6 | T2204535 Intake Duct, Airbox | Intake Duct, Airbox | 1 | $21.31 | Out of Stock | Notify Me |
| 7 | T2205661 Hose, Crankcase Breather | Hose, Crankcase Breather | 1 | $17.77 | Out of Stock | Notify Me |
| 8 | T3700050 Hose Clip, Dia 19.5-22 x 8mm | Hose Clip, Dia 19.5-22 x 8mm | 2 | $3.77 | Available to order | 2 |
| 9 | T2201434 Drain Tube, Sealed | Drain Tube, Sealed | 1 | $9.02 | Available to order | 1 |
| 10 | T3700089 Hose Clip, Dia 12.5 | Hose Clip, Dia 12.5 | 1 | $4.01 | Available to order | 1 |
| 11 | T2204602 Cover, Airbox Mldg | Cover, Airbox Mldg | 1 | $8.88 | Out of Stock | Notify Me |
| 12 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv | 4 | $2.63 | Available to order | 4 |
| 13 | T3010031 Flanged Sleeve, M6 | Flanged Sleeve, M6 | 4 | $4.19 | Backorder — Late August 2026 | 4 |
| 14 | T3701080 Band Clamp, 72mm | Band Clamp, 72mm | 1 | $9.02 | Available to order | 1 |
| 15 | T3660176 Rubber Strip | Rubber Strip | 2 | $5.02 | Out of Stock | Notify Me |
