Clutch Controls
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2043945 Clutch Lever Assembly, MCS | Clutch Lever Assembly, MCS | 1 | $129.21 | Available to order | 1 |
| 2 | T2043946 Clutch Lever, MCS, Adjustable | Clutch Lever, MCS, Adjustable Black Lever | 1 | $89.71 | Available to order | 1 |
| 3 | T2046082 Clutch Lever Bracket | Clutch Lever Bracket | 1 | $38.96 | Available to order | 1 |
| 4 | T2046524 Pivot Bolt | Pivot Bolt | 1 | $2.63 | Available to order | 1 |
| 5 | T2046520 Adjuster Screw | Adjuster Screw | 1 | $8.53 | Available to order | 1 |
| 6 | T2046521 Nut, Pivot Bolt | Nut, Pivot Bolt | 1 | $1.21 | Available to order | 1 |
| 7 | T2046510 Clamp, Clutch lever bracket | Clamp, Clutch lever bracket | 1 | $16.04 | Available to order | 1 |
| 8 | T2046522 Bolt, Handlebar Clamp | Bolt, Handlebar Clamp | 2 | $2.00 | Available to order | 2 |
| 9 | T2044199 Clutch Cable | Clutch Cable | 1 | $52.11 | Out of Stock | Notify Me |
| 10 | T3700108 Clip, Cable, 14.3 x 10 | Clip, Cable, 14.3 x 10 | 2 | $3.24 | Available to order | 2 |
| 13 | T3331750 Screw, Tx, M4 x 17.5, Slv | Screw, Tx, M4 x 17.5, Slv | 1 | $4.30 | Out of Stock | Notify Me |
