Front Forks & Lower Yoke
Parts (21)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2043977 Fork Stanchion Assy, RH | Fork Stanchion Assy, RH | 1 | $1085.30 | Available to order | 1 |
| 2 | T2043976 Fork Stanchion Assy, LH | Fork Stanchion Assy, LH | 1 | $1085.30 | Available to order | 1 |
| 3 | T2043744 Stanchion, RH | Stanchion, RH | 1 | $626.77 | Out of Stock | Notify Me |
| 4 | T2043745 Stanchion, LH | Stanchion, LH | 1 | $626.77 | Available to order | 1 |
| 5 | T2049324 Rebound Cartridge (RH) | Rebound Cartridge (RH) | 1 | $534.83 | Backorder — Late August 2026 | 1 |
| 6 | T2049325 Compression Cartridge (LH) | Compression Cartridge (LH) | 1 | $534.83 | Out of Stock | Notify Me |
| 10 | T2043751 Sealing Bush Set | Sealing Bush Set | 2 | $93.40 | Available to order | 2 |
| 11 | T2048753 Decal, Fork Leg | Decal, Fork Leg | 2 | $36.99 | Available to order | 2 |
| 12 | T2043146 Mount Post, Front Mudguard, RH | Mount Post, Front Mudguard, RH | 1 | $50.32 | Available to order | 1 |
| 13 | T2043117 Mount Post, Front Mudguard, LH | Mount Post, Front Mudguard, LH | 1 | $50.32 | Available to order | 1 |
| 14 | T3050355 Screw, Cap/Hd, M5 x 16, Slv, Enc | Screw, Cap/Hd, M5 x 16, Slv, Enc | 4 | $0.59 | Available to order | 4 |
| 15 | T2043848 Lower Yoke Assembly | Lower Yoke Assembly | 1 | $509.77 | Available to order | 1 |
| 16 | T3050324 Screw, Cap/Hd, M8 x 1.25 x 35, Slv | Screw, Cap/Hd, M8 x 1.25 x 35, Slv | 4 | $4.74 | Available to order | 4 |
| 17 | T3800091 Bearing, Sac | Bearing, Sac | 2 | $33.95 | Available to order | 2 |
| 18 | T3600234 Dust Seal, Dia 55 | Dust Seal, Dia 55 | 2 | $8.34 | Available to order | 2 |
| 19 | T2042138 Cover, Headstock Bearing | Cover, Headstock Bearing | 1 | $10.90 | Available to order | 1 |
| 20 | T2040301 Adjuster Nut, M30, Lower | Adjuster Nut, M30, Lower | 1 | $28.50 | Available to order | 1 |
| 21 | T2042738 Rubber Washer | Rubber Washer | 1 | $1.13 | Available to order | 1 |
| 22 | T2040304 Locknut, M30 | Locknut, M30 | 1 | $20.60 | Available to order | 1 |
| 23 | T2700332 Reflector, Amber, Oval | Reflector, Amber, Oval All Mkts Excpt BR & TH | 2 | $6.39 | Available to order | 2 |
| 24 | T2044184 Washer, Tabbed | Washer, Tabbed | 1 | $10.78 | Out of Stock | Notify Me |
