Rear Brake Caliper & Disc
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2022253 Disc, Rear | Disc, Rear | 1 | $234.63 | Available to order | 1 |
| 2 | T2024801 Bolt, Disc, M8 x 30, Slv, Enc | Bolt, Disc, M8 x 30, Slv, Enc | 4 | $1.90 | Available to order | 4 |
| 3 | T2021266 Rear Brake Caliper | Rear Brake Caliper | 1 | $494.36 | Available to order | 1 |
| 4 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.27 | Available to order | 1 |
| 5 | T2020954 Pad Spring Set | Pad Spring Set | 1 | $8.53 | Available to order | 1 |
| 6 | T2020050 Piston Set | Piston Set | 1 | $119.76 | Available to order | 1 |
| 7 | T2020505 Seal Kit, 2 Piston Caliper | Seal Kit, 2 Piston Caliper | 1 | $57.03 | Available to order | 1 |
| 8 | T2022955 Pad Set | Pad Set Includes 2 pads | 1 | $64.60 | Available to order | 1 |
| 9 | T2020966 Pad Pin Set (2 Pins) | Pad Pin Set (2 Pins) | 1 | $15.95 | Available to order | 1 |
| 10 | T2021269 Carrier, Rear Caliper | Carrier, Rear Caliper | 1 | $169.19 | Available to order | 1 |
| 11 | T2021707 Set, Sliding Seals | Set, Sliding Seals | 1 | $44.27 | Available to order | 1 |
