Side Panels
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2311542-HN Sidepanel, LH, Competition Green | Sidepanel, LH, Competition Green | 1 | $318.01 | Available to order | 1 |
| 2 | T2311545-HN Sidepanel, RH, Competition Green | Sidepanel, RH, Competition Green | 1 | $318.01 | Backorder — Late August 2026 | 1 |
| 3 | T2312047 Mesh, Sidepanel | Mesh, Sidepanel | 2 | $22.21 | Out of Stock | Notify Me |
| 4 | T3550253 Washer, Dia 5 mm, Retaining | Washer, Dia 5 mm, Retaining | 10 | $0.97 | Available to order | 10 |
| 5 | T2311651-HN Sidepanel Lower, LH, Competition Green | Sidepanel Lower, LH, Competition Green | 1 | $318.01 | Out of Stock | Notify Me |
| 6 | T2311652-HN Sidepanel Lower, RH, Competition Green | Sidepanel Lower, RH, Competition Green | 1 | $318.01 | Out of Stock | Notify Me |
| 7 | T2312024 Finisher, LH, HPDC | Finisher, LH, HPDC | 1 | $62.16 | Available to order | 1 |
| 8 | T2312029 Finisher, RH, HPDC | Finisher, RH, HPDC | 1 | $62.16 | Available to order | 1 |
| 9 | T2312025 Finisher Support, LH | Finisher Support, LH | 1 | $8.01 | Out of Stock | Notify Me |
| 10 | T2312030 Finisher Support, RH | Finisher Support, RH | 1 | $8.01 | Available to order | 1 |
| 11 | T3331005 Screw, But/Hd, M5 x 14, Slv, Enc | Screw, But/Hd, M5 x 14, Slv, Enc | 8 | $8.46 | Available to order | 8 |
| 12 | T3331433 Screw, S/Tap, Pan TX, 4 x 11, PT | Screw, S/Tap, Pan TX, 4 x 11, PT | 4 | $1.78 | Unavailable | View Details |
| 13 | T2313294 Frame Infill LH | Frame Infill LH | 1 | $15.11 | Available to order | 1 |
| 14 | T2313293 Frame Infill RH | Frame Infill RH | 1 | $15.11 | Out of Stock | Notify Me |
| 15 | T3020054 Grommet, Sidepanel | Grommet, Sidepanel | 8 | $2.37 | Out of Stock | Notify Me |
| 16 | T2312026 Sidepanel, Manifold Cover, LH | Sidepanel, Manifold Cover, LH | 1 | $13.33 | Out of Stock | Notify Me |
| 17 | T2312031 Sidepanel, Manifold Cover, RH | Sidepanel, Manifold Cover, RH | 1 | $13.33 | Available to order | 1 |
| 18 | T2312027 Finisher, Throttle Body Cover, LH, HPDC | Finisher, Throttle Body Cover, LH, HPDC | 1 | $44.40 | Available to order | 1 |
| 19 | T2312032 Finisher, Throttle Body Cover, RH, HPDC | Finisher, Throttle Body Cover, RH, HPDC | 1 | $35.52 | Available to order | 1 |
| 20 | T3200556 Bolt, TX, M5 x 0.8 x 25, Enc | Bolt, TX, M5 x 0.8 x 25, Enc | 4 | $2.67 | Available to order | 4 |
| 21 | T2312034 Bracket, Sidepanel, LH | Bracket, Sidepanel, LH | 1 | $11.55 | Out of Stock | Notify Me |
| 22 | T2312035 Bracket, Sidepanel, RH | Bracket, Sidepanel, RH | 1 | $11.55 | Out of Stock | Notify Me |
| 23 | T3330957 Screw, But/Hd, M5 x 12, Slv | Screw, But/Hd, M5 x 12, Slv | 4 | $8.46 | Available to order | 4 |
| 24 | T2314169 Infill, Sidepanel, LH | Infill, Sidepanel, LH | 1 | $15.11 | Out of Stock | Notify Me |
| 25 | T2312346 Moulding, Harness Cover | Moulding, Harness Cover | 1 | $11.41 | Available to order | 1 |
| 26 | T3020131 Grommet, 9 x 2 x 6 | Grommet, 9 x 2 x 6 | 6 | $2.00 | Available to order | 6 |
| 27 | T3701098 Firtree, Dia 5 x 18 | Firtree, Dia 5 x 18 | 3 | $5.24 | Available to order | 3 |
| 28 | T2318831 Decal, Sidepanel, LH, Aluminium Slv | Decal, Sidepanel, LH, Aluminium Slv | 1 | $18.08 | Out of Stock | Notify Me |
| 29 | T2318832 Decal, Sidepanel, RH, Aluminium Slv | Decal, Sidepanel, RH, Aluminium Slv | 1 | $18.08 | Out of Stock | Notify Me |
| 30 | T3450261 Firtree Plug | Firtree Plug Not Illustrated | 2 | $2.00 | Available to order | 2 |
