Crankshaft,Conn Rods & Pistons > Eng No 211132
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1100914 Crankshaft Assy | Crankshaft Assy | 1 | $974.95 | Obsolete | View Details |
| 2 | T1100913 Spacer, Crankshaft | Spacer, Crankshaft | 1 | $15.77 | Available to order | 1 |
| 3 | T1100105 Centrifugal Breather | Centrifugal Breather | 1 | $66.52 | Available to order | 1 |
| 4 | T3330186 Screw, Pan HD, Tx, M6 x 25, Slv | Screw, Pan HD, Tx, M6 x 25, Slv M6 x 25mm | 2 | $3.17 | Available to order | 2 |
| 5 | T1110111 Con Rod Assy, Short Stroke | Con Rod Assy, Short Stroke | 2 | $172.95 | Available to order | 2 |
| 6 | T1110060 Bolt Con Rod | Bolt Con Rod > Eng No 197182 | 4 | $10.55 | Backorder — Mid August 2026 | 4 |
| 6 | T1110301 Conrod Bolt, M8 x 0.75 x 42 | Conrod Bolt, M8 x 0.75 x 42 Eng No 197183 > | 2 | $13.18 | Available to order | 2 |
| 7 | T1110016 Nut, Con Rod | Nut, Con Rod > Eng No 197182 | 4 | $9.69 | Available to order | 4 |
| 8 | 1110051-T0301 Bearing, Con Rod Shell, White | Bearing, Con Rod Shell, White > Eng No 197182 | — | $4.97 | Obsolete | View Details |
| 8 | 1110052-T0301 Bearing, Con Rod Shell, Red | Bearing, Con Rod Shell, Red > Eng No 197182 | — | $6.39 | Available to order | 1 |
| 8 | 1110053-T0301 Bearing, Con Rod Shell, Blue | Bearing, Con Rod Shell, Blue > Eng No 197182 | — | $10.18 | Available to order | 1 |
| 8 | T1110054 Bearing, Con Rod Shell, White | Bearing, Con Rod Shell, White Eng No 197183 > | 2 | $10.18 | Available to order | 2 |
| 8 | T1110055 Bearing, Con Rod Shell, Red | Bearing, Con Rod Shell, Red Eng No 197183 > | 2 | $12.70 | Available to order | 2 |
| 9 | T1120900 Piston Assy | Piston Assy | 2 | $247.17 | Available to order | 2 |
| 10 | T1120800 Gudgeon pin | Gudgeon pin | 2 | $7.62 | Available to order | 2 |
| 11 | 1120015-T0301 Circlip, Piston | Circlip, Piston | 4 | $1.21 | Available to order | 4 |
| 12 | T1120903 Piston Ring Set | Piston Ring Set | 2 | $92.49 | Obsolete | View Details |
