Clutch Controls & Switches > 210261
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2046014 Switch Cube Assy, LH | Switch Cube Assy, LH | 1 | $199.87 | Obsolete | View Details |
| 2 | T2046000 Clutch Lever Assy | Clutch Lever Assy | 1 | $69.50 | Available to order | 1 |
| 3 | T2046010 Housing, Clutch Lever | Housing, Clutch Lever | 1 | $41.91 | Available to order | 1 |
| 4 | T2046001 Lever, Clutch | Lever, Clutch | 1 | $65.49 | Available to order | 1 |
| 5 | T2046515 Bolt, Clutch Pivot | Bolt, Clutch Pivot PART NO LONGER AVAILABLE | 1 | $2.85 | Obsolete | View Details |
| 6 | T2046521 Nut, Pivot Bolt | Nut, Pivot Bolt | 1 | $1.21 | Available to order | 1 |
| 7 | T2046004 Screw, M6 x 20 | Screw, M6 x 20 M6 x 20mm | 2 | $3.77 | Available to order | 2 |
| 8 | T2046520 Adjuster Screw | Adjuster Screw | 1 | $8.53 | Available to order | 1 |
| 9 | T2026004 Clamp, Handlebar | Clamp, Handlebar | 1 | $17.49 | Available to order | 1 |
| 10 | T2046005 Switch Set, LH | Switch Set, LH | 1 | $165.39 | Available to order | 1 |
| 11 | T3330018 Screw, Phil, Pan/Hd, M5 x 25 | Screw, Phil, Pan/Hd, M5 x 25 M5 x 25mm | 1 | $2.17 | Available to order | 1 |
| 12 | T3330382 Screw, Phil Pan HD, M5 x 12, Slv | Screw, Phil Pan HD, M5 x 12, Slv | 1 | $0.44 | Available to order | 1 |
