Ignition System
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1290131 Crankshaft Position Sensor/Ignition Pick-Up | Crankshaft Position Sensor/Ignition Pick-Up | 1 | $106.47 | Available to order | 1 |
| 2 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.40 | Available to order | 2 |
| 3 | T1290046 Ignition coil | Ignition coil 3 Cyl | 2 | $263.76 | Available to order | 2 |
| 4 | T3330728 Screw, Pan/Hd, Tx, M5 x 16, Enc | Screw, Pan/Hd, Tx, M5 x 16, Enc | 4 | $0.97 | Available to order | 4 |
| 5 | T1290000 Ignition cable, 2 Cyl | Ignition cable, 2 Cyl | 2 | $92.25 | Available to order | 2 |
| 6 | T1290024 Spark Plug, DPR8EA-9 | Spark Plug, DPR8EA-9 DPR8EA-9 | 2 | $7.34 | Available to order | 2 |
| 7 | T1292370 Igniter, 8000 Rpm, 270 Twin | Igniter, 8000 Rpm, 270 Twin 210262 > | 1 | $492.91 | Available to order | 1 |
| 7 | T1292060 Igniter | Igniter > 210261 | 1 | $492.91 | Out of Stock | Notify Me |
| 8 | T3300006 Rivet, Barbed, 12.7-20.6 mm | Rivet, Barbed, 12.7-20.6 mm | 4 | $1.06 | Available to order | 4 |
| 9 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 2 | $3.50 | Available to order | 2 |
| 10 | T1291060 Bracket | Bracket | 1 | $10.96 | Obsolete | View Details |
| 11 | T3351002 Nut, Captive, U-Type, M5, Slv | Nut, Captive, U-Type, M5, Slv | 4 | $2.37 | Available to order | 4 |
