Front Wheel 469051 >
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2000329 Front Wheel Assembly, 19 x 2.5 | Front Wheel Assembly, 19 x 2.5 > 617620 | 1 | $924.18 | Backorder — Early August 2026 | 1 |
| 1 | T2000327 Wheel Assy, Front, 19 x 2.5, Black | Wheel Assy, Front, 19 x 2.5, Black 617621 > | 1 | $959.40 | Out of Stock | Notify Me |
| 2 | T3800704 Bearing, Ball, 25 47 12 | Bearing, Ball, 25 47 12 | 2 | $43.81 | Available to order | 2 |
| 3 | T3600705 Oil Seal, 35 47 6 | Oil Seal, 35 47 6 | 2 | $9.10 | Available to order | 2 |
| 4 | T2003531 Spacer, Internal | Spacer, Internal | 1 | $46.19 | Backorder — Late August 2026 | 1 |
| 5 | T3500402 Circlip, Int Dia 47 | Circlip, Int Dia 47 | 1 | $0.89 | Available to order | 1 |
| 6 | T2006615 Valve Assy, aluminium, 90, Slv | Valve Assy, aluminium, 90, Slv > 617620 | 1 | $16.04 | Available to order | 1 |
| 6 | T2006635 Valve Assy, Alum, 90, Black | Valve Assy, Alum, 90, Black 617621 > | 1 | $16.04 | Available to order | 1 |
| 7 | T2005204 Spacer | Spacer | 2 | $11.88 | Available to order | 2 |
| 8 | T2000195 Spindle, Front Wheel | Spindle, Front Wheel | 1 | $91.26 | Available to order | 1 |
