Front Brake Caliper & Discs
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2020542 Caliper Assy, Front | Caliper Assy, Front > 661676 | 1 | $730.56 | Available to order | 1 |
| 1 | T2026272 Caliper Assy, LH | Caliper Assy, LH 661677 > 673348 | 1 | $730.56 | Available to order | 1 |
| 2 | T2020546 Caliper Assy, Front, RH | Caliper Assy, Front, RH > 469050 | 1 | $721.76 | Available to order | 1 |
| 3 | T2020543 Brake Pad Set, x 2 Pads | Brake Pad Set, x 2 Pads | 2 | $68.07 | Available to order | 2 |
| 4 | T2020505 Seal Kit, 2 Piston Caliper | Seal Kit, 2 Piston Caliper | 2 | $57.03 | Available to order | 2 |
| 5 | T2020050 Piston Set | Piston Set | 2 | $119.76 | Available to order | 2 |
| 6 | T2020014 Bleed Screw | Bleed Screw | 2 | $15.27 | Available to order | 2 |
| 7 | T2020084 Pad Pin Set, D Spec | Pad Pin Set, D Spec | 2 | $15.95 | Available to order | 2 |
| 8 | T2020086 Pad, Spring, D Spec | Pad, Spring, D Spec | 2 | $10.34 | Available to order | 2 |
| 9 | T2025438 Bracket, Caliper, LH | Bracket, Caliper, LH | 1 | $59.87 | Available to order | 1 |
| 9 | T2025439 Bracket, Caliper, RH | Bracket, Caliper, RH > 469050 | 1 | $59.87 | Available to order | 1 |
| 10 | T2023351 Disc, Front, Pair | Disc, Front, Pair > 392059 | 2 | $457.01 | Available to order | 2 |
| 10 | T2023344 Disc, Front, LHS, Dia 310 | Disc, Front, LHS, Dia 310 392060 > 469050 | 1 | $258.42 | Available to order | 1 |
| 11 | T3200601 Bolt, HHF, M8 x 40, Slv | Bolt, HHF, M8 x 40, Slv > 513202 | 4 | $3.04 | Available to order | 4 |
| 12 | T2029090 Spares Kit, Disc Bolts | Spares Kit, Disc Bolts > 372113 - Kit contains 12 bolts | 1 | $71.34 | Available to order | 1 |
| 12 | T2020608 Bolt, Disc, M8 x 18, Slv | Bolt, Disc, M8 x 18, Slv 372114 > 469050 | 12 | $9.84 | Available to order | 12 |
| 12 | T2024801 Bolt, Disc, M8 x 30, Slv, Enc | Bolt, Disc, M8 x 30, Slv, Enc 469051 > | 5 | $1.90 | Available to order | 5 |
| 13 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome > 469050 | 12 | $4.19 | Backorder — Mid August 2026 | 12 |
| 14 | T2023345 Disc, Front, RHS, Dia 310 | Disc, Front, RHS, Dia 310 392060 > 469050 | 1 | $258.42 | Out of Stock | Notify Me |
| 15 | T3550184 Washer, Hardened, 8.2 x 18.7 x 2 | Washer, Hardened, 8.2 x 18.7 x 2 513203 > | 2 | $2.25 | Available to order | 2 |
| 16 | T2023370 Disc, Front LHs, Dia 310 | Disc, Front LHs, Dia 310 469051 > | 1 | $251.26 | Available to order | 1 |
| 17 | T2021707 Set, Sliding Seals | Set, Sliding Seals | 1 | $44.27 | Available to order | 1 |
