Rear Brake Caliper & Disc
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2023030 Caliper Assy, 2 Piston, LH | Caliper Assy, 2 Piston, LH > 661676 | 1 | $1073.83 | Available to order | 1 |
| 1 | T2023051 Caliper, Rear | Caliper, Rear 661677 > 673348 | 1 | $1073.83 | Out of Stock | Notify Me |
| 2 | T2020966 Pad Pin Set (2 Pins) | Pad Pin Set (2 Pins) | 1 | $15.95 | Available to order | 1 |
| 3 | T2020954 Pad Spring Set | Pad Spring Set | 1 | $8.53 | Available to order | 1 |
| 4 | T2020071 Pad Set, 2P Caliper, LH | Pad Set, 2P Caliper, LH | 1 | $57.42 | Available to order | 1 |
| 5 | T2020050 Piston Set | Piston Set | 1 | $119.76 | Available to order | 1 |
| 6 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.27 | Available to order | 1 |
| 7 | T2026045 Caliper Carrier | Caliper Carrier | 1 | $157.79 | Available to order | 1 |
| 8 | T2029090 Spares Kit, Disc Bolts | Spares Kit, Disc Bolts > 372113 - Kit contains 12 bolts | 1 | $71.34 | Available to order | 1 |
| 8 | T2020608 Bolt, Disc, M8 x 18, Slv | Bolt, Disc, M8 x 18, Slv 372114 > 469050 | 5 | $9.84 | Available to order | 5 |
| 8 | T2024801 Bolt, Disc, M8 x 30, Slv, Enc | Bolt, Disc, M8 x 30, Slv, Enc 469051 > | 5 | $1.90 | Available to order | 5 |
| 9 | T2023355 Disc, Rear, Dia 285 | Disc, Rear, Dia 285 | 1 | $249.48 | Available to order | 1 |
| 10 | T3205687 Bolt, HHF, Lghtd, M10 x 19, Slv | Bolt, HHF, Lghtd, M10 x 19, Slv | 2 | $9.02 | Available to order | 2 |
| 11 | T2020898 Wire Guide, Brake Hose | Wire Guide, Brake Hose | 1 | $3.39 | Available to order | 1 |
| 12 | T3205062 Bolt, HHF, Lghtd, M6 x 12, Slv | Bolt, HHF, Lghtd, M6 x 12, Slv | 1 | $4.19 | Available to order | 1 |
| 13 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome > 372113 | 6 | $4.19 | Backorder — Mid August 2026 | 6 |
| 14 | T2021707 Set, Sliding Seals | Set, Sliding Seals | 1 | $44.27 | Available to order | 1 |
