Clutch
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1179094 Clutch Assembly | Clutch Assembly | 1 | $1109.05 | Available to order | 1 |
| 2 | T1170950 Bolt, M6 x 28 | Bolt, M6 x 28 > Eng No 460047 | 4 | $7.71 | Available to order | 4 |
| 2 | T1170507 Special Bolt, M6 x 20, Slv | Special Bolt, M6 x 20, Slv Eng No 460048 > | 4 | $1.91 | Available to order | 4 |
| 3 | T1171360 Spring | Spring > 432776 | 4 | $5.30 | Backorder — Mid August 2026 | 4 |
| 3 | T1171510 Spring | Spring 432777 > Eng No 447017 | 4 | $5.30 | Available to order | 4 |
| 4 | T1179098 Plate, Clutch Pressure | Plate, Clutch Pressure | 1 | $249.05 | Available to order | 1 |
| 5 | T1170907 Disc, Friction Clutch, A | Disc, Friction Clutch, A | 2 | $20.36 | Available to order | 2 |
| 6 | T1170554 Plate, A, Clutch | Plate, A, Clutch | 6 | $22.92 | Available to order | 6 |
| 7 | T1171365 Disc, Friction Clutch, B | Disc, Friction Clutch, B | 5 | $20.36 | Available to order | 5 |
| 8 | T1179097 Centre Drum, Clutch | Centre Drum, Clutch | 1 | $327.43 | Available to order | 1 |
| 9 | T1179095 Outer Drum | Outer Drum | 1 | $836.15 | Available to order | 1 |
| 10 | T1179099 Plate Assy, Lifter, Clutch | Plate Assy, Lifter, Clutch | 1 | $142.58 | Available to order | 1 |
| 11 | T1170996 Aux Gear Comp, Oil Pump Drive | Aux Gear Comp, Oil Pump Drive | 1 | $148.31 | Available to order | 1 |
| 12 | T1170018 Bush, Clutch | Bush, Clutch | 1 | $57.16 | Obsolete | View Details |
| 13 | T1170192 Nut, Clutch, M22 | Nut, Clutch, M22 | 1 | $12.29 | Available to order | 1 |
| 14 | T1179999 Washer, C, Clutch | Washer, C, Clutch | 1 | $11.71 | Available to order | 1 |
| 15 | T1171399 Lifter Piece, Clutch | Lifter Piece, Clutch | 1 | $41.82 | Available to order | 1 |
| 16 | T3550236 Washer, 14 x 20 x 1.6 | Washer, 14 x 20 x 1.6 > 432777 | 1 | $2.95 | Available to order | 1 |
| 18 | T1179096 Brg, Needle 35 x 42 x 23 | Brg, Needle 35 x 42 x 23 | 1 | $81.75 | Available to order | 1 |
