Large Saddlebag Kit
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9508159 Large Saddlebag Kit | Large Saddlebag Kit | 1 | $187.00 | Obsolete | View Details |
| 2 | A9520019 Saddlebag, Large, Pair | Saddlebag, Large, Pair | 1 | $126.00 | Obsolete | View Details |
| 3 | A9500509 Pannier Rail, LHS | Pannier Rail, LHS | 1 | $52.92 | Obsolete | View Details |
| 4 | A9500508 Pannier Rail, RHS | Pannier Rail, RHS | 1 | $20.95 | Obsolete | View Details |
| 5 | A9910879 Spacer, 8.2 x 14.8 x 8.3 | Spacer, 8.2 x 14.8 x 8.3 | 4 | $7.56 | Obsolete | View Details |
| 6 | A9910881 Screw, Cap/Hd, M8 x 45, Slv | Screw, Cap/Hd, M8 x 45, Slv | 4 | $2.16 | Obsolete | View Details |
| 7 | T3450062 Plug, Plastic, Black | Plug, Plastic, Black | 4 | $1.40 | Available to order | 4 |
| 8 | T2707111 Reflex Reflector | Reflex Reflector | 2 | $9.88 | Available to order | 2 |
| 9 | T3550253 Washer, Dia 5 mm, Retaining | Washer, Dia 5 mm, Retaining | 4 | $0.97 | Available to order | 4 |
