Oil Pump & Drive
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1213141 Oil Pump | Oil Pump | 1 | $293.96 | Available to order | 1 |
| 2 | T3201029 Bolt, RHHF, M6 x 40, Raw | Bolt, RHHF, M6 x 40, Raw | 3 | $2.10 | Backorder — Early September 2026 | 3 |
| 3 | T1210810 Sprocket, Oil Pump Drive, 25T | Sprocket, Oil Pump Drive, 25T | 1 | $34.32 | Available to order | 1 |
| 4 | T1210816 Chain, 52 Link | Chain, 52 Link | 1 | $115.71 | Available to order | 1 |
| 5 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 1 | $1.40 | Available to order | 1 |
| 6 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv | 1 | $2.00 | Available to order | 1 |
| 7 | T1211065 Pressure Relief Valve | Pressure Relief Valve | 1 | $37.15 | Available to order | 1 |
| 8 | T1210999 Sleeve, Oil Jet, Piston, 1.2Mm | Sleeve, Oil Jet, Piston, 1.2Mm | 3 | $6.14 | Available to order | 3 |
