Swinging Arm Sprint Sport/Sprint Executive
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2056832 Swinging arm assembly | Swinging arm assembly Sprint Sport - Includes bearings etc | 1 | $1208.37 | Obsolete | View Details |
| 1 | T2056835 Swinging arm assembly | Swinging arm assembly Sprint Executive - Includes bearings etc | 1 | $1208.37 | Obsolete | View Details |
| 2 | T2010054 Eccentric adjuster | Eccentric adjuster Black | 2 | $30.13 | Obsolete | View Details |
| 3 | T3050064 Capscrew | Capscrew M10 x 40mm Black | 2 | $3.12 | Obsolete | View Details |
| 4 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv | 2 | $2.14 | Available to order | 2 |
| 5 | 2056920-T0301 Rubbing strip | Rubbing strip | 1 | $29.99 | Obsolete | View Details |
| 6 | T3010144 Flanged Sleeve, M6 x 9.5 x 10.5 | Flanged Sleeve, M6 x 9.5 x 10.5 Sprint Sport | 2 | $4.01 | Available to order | 2 |
| 7 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 2 | $1.50 | Available to order | 2 |
| 8 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 2 | $1.13 | Available to order | 2 |
| 9 | 2056002-T0301 Spindle | Spindle | 1 | $110.55 | Obsolete | View Details |
| 10 | 2056960-T0301 Sleeve | Sleeve PART NO LONGER AVAILABLE | 2 | $29.00 | Obsolete | View Details |
| 11 | T2056008 Thrust Seal | Thrust Seal | 4 | $13.22 | Obsolete | View Details |
| 12 | 2056970-T0301 Shim | Shim PART NO LONGER AVAILABLE | 4 | $2.21 | Obsolete | View Details |
| 13 | T3800014 Roller bearing | Roller bearing | 4 | $14.85 | Available to order | 4 |
| 14 | T2056994 Plug | Plug | 2 | $24.27 | Obsolete | View Details |
| 15 | T3555032 Washer, 17 x 30 x 3 | Washer, 17 x 30 x 3 M14 | 1 | $3.37 | Available to order | 1 |
| 16 | T2056020 Bolt special | Bolt special | 1 | $30.55 | Obsolete | View Details |
| 17 | T3900092 Label, Chain & Tyres | Label, Chain & Tyres Chain & Tyres | 1 | $6.06 | Available to order | 1 |
| 18 | 2079213-T0301 Spacer tube | Spacer tube | 1 | $15.20 | Obsolete | View Details |
| 19 | T3350042 Riv nut | Riv nut Round | — | $4.05 | Obsolete | View Details |
| 20 | T3900131 Label | Label Catalytic convertor DE | 1 | $5.47 | Obsolete | View Details |
| 21 | T3350020 Nut, Rivet, M5 | Nut, Rivet, M5 Sprint Executive | 1 | $2.04 | Available to order | 1 |
