Evaporative Loss Equipment California only
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2400160 Carbon Canister | Carbon Canister | 1 | $55.04 | Obsolete | View Details |
| 2 | T1240802 Purge Valve, EFI Replaced by T1245822 — Spares Kit, Purge Valve | Purge Valve, EFI | 1 | $61.50 | Unavailable | View Details |
| 3 | T1242536 Tube assembly | Tube assembly | 1 | $24.44 | Obsolete | View Details |
| 4 | T1242537 Tube assembly | Tube assembly | 1 | $24.57 | Obsolete | View Details |
| 5 | T1242533 Tube | Tube | 1 | $23.96 | Obsolete | View Details |
| 6 | T3700016 Cable Tie, 370 Long | Cable Tie, 370 Long | 2 | $1.01 | Available to order | 2 |
| 7 | T1240556 Bracket | Bracket | 1 | $24.63 | Obsolete | View Details |
| 8 | T1242534 Tube assembly | Tube assembly | 1 | $4.01 | Obsolete | View Details |
| 9 | T3622503 Pipe, Fuel, 40mm | Pipe, Fuel, 40mm | 1 | $3.93 | Backorder — Early October 2026 | 1 |
| 10 | T2400045 Valve, Roll Over | Valve, Roll Over Rollover | 1 | $36.67 | Unavailable | View Details |
