Ignition Switch & Lockset
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2500879 Lockset | Lockset | 1 | $712.97 | Backorder — Late August 2026 | 1 |
| 2 | T2509617 Ignition Lock, Combined | Ignition Lock, Combined | 1 | $272.95 | Out of Stock | Notify Me |
| 3 | T2400718 Fuel Filler Cap, Locking | Fuel Filler Cap, Locking Includes 2 keys | 1 | $121.69 | Available to order | 1 |
| 4 | T2501924 Seat Lock Assembly | Seat Lock Assembly | 1 | $125.46 | Available to order | 1 |
| 5 | T2501922 Seat Lock, Panel Mount | Seat Lock, Panel Mount | 1 | $30.70 | Out of Stock | Notify Me |
| 6 | T2505616 Clip, Seat Lock | Clip, Seat Lock | 1 | $9.97 | Available to order | 1 |
| 7 | T2501123 Latch Assy, Seat | Latch Assy, Seat | 1 | $33.01 | Available to order | 1 |
| 8 | T2500506 Seat Latch Housing | Seat Latch Housing | 1 | $33.01 | Available to order | 1 |
| 9 | T2501124 Cable, Seat Lock | Cable, Seat Lock | 1 | $27.68 | Out of Stock | Notify Me |
| 10 | T2504577 Key, Cut, Immobiliser | Key, Cut, Immobiliser Supplied as pair | 1 | $79.02 | Out of Stock | Notify Me |
| 10 | T2504578 Key, Blank, Immobiliser | Key, Blank, Immobiliser Supplied as single | 2 | $72.26 | Available to order | 2 |
| 11 | T2501725 Cable Bracket, Seat Lock | Cable Bracket, Seat Lock | 1 | $14.83 | Available to order | 1 |
| 12 | T3330184 Screw, C'sunk Tx, M6 x 25, Slv | Screw, C'sunk Tx, M6 x 25, Slv | 2 | $1.27 | Available to order | 2 |
| 13 | T3330327 Bolt, Shear, M6 x 22, Enc | Bolt, Shear, M6 x 22, Enc | 2 | $5.24 | Available to order | 2 |
| 14 | T3550436 Washer, M6, Elongated | Washer, M6, Elongated | 2 | $4.45 | Available to order | 2 |
| 15 | T2504061 Immobiliser ECU, with RF 434 | Immobiliser ECU, with RF 434 All Except JP | 1 | $1452.32 | Available to order | 1 |
| 15 | T2504071 Immobiliser ECU, with RF 315 | Immobiliser ECU, with RF 315 JP Only | 1 | $1452.32 | Available to order | 1 |
| 16 | T3330429 Screw, Skt Hd, M5 x 25, SS | Screw, Skt Hd, M5 x 25, SS | 1 | $2.20 | Available to order | 1 |
| 17 | T3350129 Nut, Captive, M5 | Nut, Captive, M5 | 2 | $3.39 | Available to order | 2 |
| 18 | T2501778 Moulding, Bracket, Immobiliser | Moulding, Bracket, Immobiliser > 754088 | 1 | $9.41 | Available to order | 1 |
| 18 | T2504009 Moulding, Bracket, Immobiliser | Moulding, Bracket, Immobiliser 754089 > | 1 | $9.41 | Backorder — Late August 2026 | 1 |
| 19 | T3331234 Screw, Torx, P/H, M6 x 20, Slv | Screw, Torx, P/H, M6 x 20, Slv | 2 | $5.30 | Available to order | 2 |
| 20 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 1 | $0.89 | Available to order | 1 |
| 21 | T2503350 Bracket, Seat Latch | Bracket, Seat Latch | 1 | $1.72 | Available to order | 1 |
