Chrome Wheels Kit
Schematic
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9648039 Chrome Wheels | Chrome Wheels Market Restrictions Apply - Rim tapes & inner tubes required for installation | 1 | $965.00 | Obsolete | View Details |
| 2 | T2000758 Front Wheel Assembly, 18 x 2.75 | Front Wheel Assembly, 18 x 2.75 | 1 | $941.81 | Available to order | 1 |
| 3 | T2011005 Rear Wheel Assy, Spoked, 17 x 4.25 | Rear Wheel Assy, Spoked, 17 x 4.25 | 1 | $1689.96 | Available to order | 1 |
| 4 | T2024801 Bolt, Disc, M8 x 30, Slv, Enc | Bolt, Disc, M8 x 30, Slv, Enc | 9 | $1.90 | Available to order | 9 |
| 5 | T2025018 Damper, Front Brake | Damper, Front Brake For Floating Discs | 1 | $72.26 | Available to order | 1 |
| 6 | T2021948 Damper, Brake Disc, LHS | Damper, Brake Disc, LHS For Solid Discs | 1 | $69.50 | Available to order | 1 |
| 7 | T2023388 Front Disc, Solid, Dia 310 | Front Disc, Solid, Dia 310 | 1 | $251.26 | Available to order | 1 |
| 12 | T2005003 Nipple, Steel, Spoke | Nipple, Steel, Spoke | 32 | $6.39 | Available to order | 32 |
| 13 | T2001034 Spoke, Front Wheel, 169.3mm | Spoke, Front Wheel, 169.3mm | 16 | $5.88 | Available to order | 16 |
| 14 | T2001036 Spoke, Front Wheel, 188.0mm | Spoke, Front Wheel, 188.0mm | 16 | $5.30 | Available to order | 16 |
| 15 | T2000563 Spoke, Front Wheel, 170.6mm | Spoke, Front Wheel, 170.6mm | 16 | $5.78 | Available to order | 16 |
| 16 | T2000564 Spoke, Front Wheel, 181.6mm | Spoke, Front Wheel, 181.6mm | 16 | $5.78 | Available to order | 16 |
| 17 | T2010424 Spoke, Rear, 152mm | Spoke, Rear, 152mm | 32 | $6.73 | Backorder — Early August 2026 | 32 |
