Panniers, Waxed Cotton, Black
Schematic
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9518155 Panniers, Waxed Cotton, Black | Panniers, Waxed Cotton, Black Replaced by A9518156 & A9518157 - Also requires A9950009 - Market restrictions may apply | 1 | $790.00 | Obsolete | View Details |
| 2 | T9510252 Pannier, RH, Wax Cotton, Black | Pannier, RH, Wax Cotton, Black | 1 | $473.80 | Unavailable | View Details |
| 3 | T9510253 Pannier, LH, Wax Cotton, Black | Pannier, LH, Wax Cotton, Black | 1 | $390.00 | Obsolete | View Details |
| 4 | T2350784 Pannier Rail, RHS, Chrome | Pannier Rail, RHS, Chrome | 1 | $173.29 | Available to order | 1 |
| 5 | T9510440 Pannier Rail, LHS, Chrome | Pannier Rail, LHS, Chrome * PART NO LONGER AVAILABLE * | 1 | $111.00 | Obsolete | View Details |
| 6 | T3205469 Bolt, HHF, Lghtd, M8 x 20, Enc | Bolt, HHF, Lghtd, M8 x 20, Enc | 2 | $4.92 | Available to order | 2 |
| 7 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 2 | $2.45 | Available to order | 2 |
| 8 | T3331234 Screw, Torx, P/H, M6 x 20, Slv | Screw, Torx, P/H, M6 x 20, Slv | 4 | $5.30 | Available to order | 4 |
| 9 | T9510257 Harness, RH, Pannier | Harness, RH, Pannier | 1 | $59.47 | Available to order | 1 |
| 10 | T9510258 Harness, LH, Pannier | Harness, LH, Pannier | 1 | $42.00 | Unavailable | View Details |
| 11 | T9910908 Sleeve, Flgd, 6.4 x 11.5 x 4 | Sleeve, Flgd, 6.4 x 11.5 x 4 | 4 | $4.45 | Available to order | 4 |
| 12 | T2700443 Reflector, Oval, Red | Reflector, Oval, Red | 2 | $6.14 | Available to order | 2 |
| 13 | T9510271 Reflector Bracket, RH | Reflector Bracket, RH | 1 | $14.04 | Available to order | 1 |
| 14 | T9510272 Reflector Bracket, LH | Reflector Bracket, LH | 1 | $14.04 | Available to order | 1 |
