Triumph Street Scrambler & Scrambler 900 Front Forks & Lower Yokes - 914448 > — OEM Parts Diagram

Triumph Waukesha is your source for OEM Triumph parts, accessories, and interactive schematics.OEM Triumph parts and schematics

Loading schematic...

What Our Customers Say

4.9 out of 5 based on 175 reviews

View all reviews →

“Thanks.”

B. BOUTET · SANTA MARIA, CA · Apr 2026

“So far excellent”

K. Colmark · Pharr, TX · Mar 2026

“great shop. easy to search/navigate for parts”

B. Hobratschk · Buda, TX · Feb 2026

“Very Smooth”

D. Haynes · GREENBACKVILLE, VA · Feb 2026

“Great inventory!”

S. Saenz · IDAHO FALLS, ID · Feb 2026

“This is my favorite Triumph OEM store on the planet”

C. Bozonier · VENTURA, CA · Jan 2026

#	Part Number	Description	Qty	Price	Status
1	T2042330 Stanchion Assy, RH	Stanchion Assy, RH	1	$1194.84	Out of Stock	Notify Me
2	T2042331 Stanchion Assy, LH	Stanchion Assy, LH	1	$1194.84	Available to order	1 Ships within 3–7 business days
3	T2042603 Cap	Cap	2	$81.75	Available to order	2 Ships within 3–7 business days
4	T2047113 O Ring, Fork Seal	O Ring, Fork Seal	2	$2.74	Available to order	2 Ships within 3–7 business days
5	T2040072 Nut, Cap Assy	Nut, Cap Assy	1	$17.56	Backorder — Late August 2026	1
6	T2041673 Spacer	Spacer	2	$11.71	Available to order	2 Ships within 3–7 business days
7	T2047151 Washer	Washer	3	$1.27	Available to order	3 Ships within 3–7 business days
8	T2042779 Spring	Spring	2	$102.64	Available to order	2 Ships within 3–7 business days
11	T2043727 Cylinder Comp, RH	Cylinder Comp, RH	1	$327.52	Out of Stock	Notify Me
12	T2043726 Cylinder Comp, LH	Cylinder Comp, LH	1	$327.52	Available to order	1 Ships within 3–7 business days
13	T2042789 Tube Comp, Inner, RH	Tube Comp, Inner, RH	1	$271.12	Available to order	1 Ships within 3–7 business days
14	T2042712 Tube Comp, Inner, LH	Tube Comp, Inner, LH	1	$271.12	Available to order	1 Ships within 3–7 business days
15	T2045157 Clip, Gaiter, Front Forks	Clip, Gaiter, Front Forks	2	$3.59	Available to order	2 Ships within 3–7 business days
16	T2040399 Screw, Fork Gaiter Clip, M4	Screw, Fork Gaiter Clip, M4	2	$3.59	Available to order	2 Ships within 3–7 business days
17	T2044069 Fork Gaiter Replaced by T2044087 — Fork Gaiter — Available	Fork Gaiter	2	$40.04	Unavailable	View Details
18	T2041670 Piece Comp, Oil Lock	Piece Comp, Oil Lock	1	$10.63	Available to order	1 Ships within 3–7 business days
19	T2045311 Oil Lock	Oil Lock	1	$39.44	Available to order	1 Ships within 3–7 business days
20	T2047109 Dust Seal, Fork	Dust Seal, Fork	2	$18.30	Backorder — Late August 2026	2
21	T2040248 Snap Ring	Snap Ring	2	$6.73	Available to order	2 Ships within 3–7 business days
22	T2044161 Oil Seal	Oil Seal	2	$24.04	Available to order	2 Ships within 3–7 business days
23	T2047107 Ring, Back Up	Ring, Back Up	2	$4.36	Backorder — Late August 2026	2
24	T2047106 Guide, Bushing	Guide, Bushing	2	$13.51	Available to order	2 Ships within 3–7 business days
25	T2042718 Tube, Outer, RH	Tube, Outer, RH	1	$645.89	Available to order	1 Ships within 3–7 business days
26	T2042684 Tube, Outer, LH	Tube, Outer, LH	1	$645.89	Available to order	1 Ships within 3–7 business days
27	T2045045 Washer, Sealing B	Washer, Sealing B	2	$1.13	Available to order	2 Ships within 3–7 business days
28	T2045046 Capscrew, Oil Lock	Capscrew, Oil Lock	2	$10.63	Available to order	2 Ships within 3–7 business days
29	T3050133 Capscrew	Capscrew	1	$4.55	Backorder — Early October 2026	1
30	T2043741 Spacer, Front Fork	Spacer, Front Fork	1	$21.41	Out of Stock	Notify Me
31	T2042371 Lower Yoke Assembly	Lower Yoke Assembly	1	$496.77	Available to order	1 Ships within 3–7 business days
32	T3600063 Seal, Dust, Dia 55	Seal, Dust, Dia 55	1	$8.34	Available to order	1 Ships within 3–7 business days
33	T3800052 Bearing, Sac, 55 x 30 x 17	Bearing, Sac, 55 x 30 x 17	1	$33.95	Available to order	1 Ships within 3–7 business days
34	T2048899 Capscrew, M10 x 30, SS, Enc	Capscrew, M10 x 30, SS, Enc	2	$8.09	Available to order	2 Ships within 3–7 business days
35	T3800091 Bearing, Sac	Bearing, Sac	1	$33.95	Available to order	1 Ships within 3–7 business days
36	T3600234 Dust Seal, Dia 55	Dust Seal, Dia 55	1	$8.34	Available to order	1 Ships within 3–7 business days
37	T2042138 Cover, Headstock Bearing	Cover, Headstock Bearing	1	$10.90	Available to order	1 Ships within 3–7 business days
38	T2040301 Adjuster Nut, M30, Lower	Adjuster Nut, M30, Lower	1	$28.50	Available to order	1 Ships within 3–7 business days
39	T2044183 Washer, Headstock	Washer, Headstock	1	$8.30	Available to order	1 Ships within 3–7 business days
40	T2040304 Locknut, M30	Locknut, M30	1	$20.60	Available to order	1 Ships within 3–7 business days
41	T3450060 Cap	Cap	1	$1.40	Available to order	1 Ships within 3–7 business days
43	T3330958 Screw, But/Hd, M5 x 10, Blk, Enc	Screw, But/Hd, M5 x 10, Blk, Enc	4	$0.97	Available to order	4 Ships within 3–7 business days
44	T2700332 Reflector, Amber, Oval	Reflector, Amber, Oval	2	$6.39	Available to order	2 Ships within 3–7 business days
