Side Fairing Panels - Cosmic Yellow/Graphite Bikes
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2311574-PG Sidepanel, RH, Jet Black | Sidepanel, RH, Jet Black | 1 | $361.13 | Backorder — Late August 2026 | 1 |
| 2 | T2318611-PG Sidepanel, LH, Jet Black | Sidepanel, LH, Jet Black | 1 | $378.74 | Available to order | 1 |
| 3 | T2311575 Decal, Sidepanel, 900, Graphite | Decal, Sidepanel, 900, Graphite | 1 | $38.99 | Out of Stock | Notify Me |
| 5 | T2302776 Infill, Sidepanel, LH | Infill, Sidepanel, LH | 1 | $23.35 | Out of Stock | Notify Me |
| 6 | T3701098 Firtree, Dia 5 x 18 | Firtree, Dia 5 x 18 | 3 | $5.24 | Available to order | 3 |
| 7 | T3020054 Grommet, Sidepanel | Grommet, Sidepanel | 5 | $2.37 | Out of Stock | Notify Me |
| 8 | T2305738 Allen Key, 4mm | Allen Key, 4mm | 1 | $5.42 | Available to order | 1 |
| 9 | T3020106 Grommet, Frame, Mushroom | Grommet, Frame, Mushroom | 1 | $2.85 | Backorder — Early August 2026 | 1 |
| 10 | T2306492 Heatshield, Sidepanel | Heatshield, Sidepanel | 1 | $56.07 | Backorder — Late August 2026 | 1 |
| 11 | T3350050 Wellnut, M5 | Wellnut, M5 | 5 | $6.65 | Available to order | 5 |
| 12 | T3330941 Screw, But/Hd, Skt, M5 x 16, Slv | Screw, But/Hd, Skt, M5 x 16, Slv | 3 | $6.73 | Available to order | 3 |
| 13 | T3551290 Washer, Nylon, 14.0 x 6.4 x 1.2 | Washer, Nylon, 14.0 x 6.4 x 1.2 | 2 | $4.30 | Available to order | 2 |
| 14 | T3330696 Screw, But/Hd, M5 X 16, Slv | Screw, But/Hd, M5 X 16, Slv | 2 | $5.69 | Available to order | 2 |
| 15 | T3660174 Rubber Pad, 25 x 25 x 10mm | Rubber Pad, 25 x 25 x 10mm | 1 | $6.39 | Available to order | 1 |
| 16 | T2311398 Board, Sidepanel, 900 | Board, Sidepanel, 900 | 1 | $118.25 | Available to order | 1 |
