Throttle Bodies
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1243320 Throttle Body Assembly, Single | Throttle Body Assembly, Single | 1 | $466.48 | Available to order | 1 |
| 2 | T1242250 Fuel Rail Assy, Low Flow | Fuel Rail Assy, Low Flow | 1 | $272.39 | Out of Stock | Notify Me |
| 3 | T1242261 Fuel Rail Assy | Fuel Rail Assy | 1 | $243.93 | Out of Stock | Notify Me |
| 4 | T1242240 Injector Assembly, Low Flow | Injector Assembly, Low Flow | 2 | $218.63 | Available to order | 2 |
| 5 | T1241965 O Ring, Injector, Upper | O Ring, Injector, Upper | 2 | $5.42 | Available to order | 2 |
| 6 | T1241966 O Ring, Injector, Lower | O Ring, Injector, Lower | 2 | $5.42 | Available to order | 2 |
| 7 | T1241967 Clip, Injector | Clip, Injector | 2 | $5.78 | Available to order | 2 |
| 8 | T3205075 Bolt, HHF, Lghtd, M6 x 65, Slv | Bolt, HHF, Lghtd, M6 x 65, Slv | 2 | $3.77 | Available to order | 2 |
| 9 | T1242786 Spacer, Fuel Rail, Aluminium | Spacer, Fuel Rail, Aluminium | 2 | $5.60 | Available to order | 2 |
| 10 | T3200190 Bolt, RHHF, M6 x 25, Slv | Bolt, RHHF, M6 x 25, Slv | 4 | $2.63 | Available to order | 4 |
| 11 | T1241997 Y Piece, Inlet | Y Piece, Inlet | 1 | $209.11 | Available to order | 1 |
| 12 | T3205093 Bolt, HHF, Lghtd, M6 x 50, Slv | Bolt, HHF, Lghtd, M6 x 50, Slv | 4 | $6.73 | Available to order | 4 |
| 13 | T1241996 Intake Seal | Intake Seal | 3 | $6.94 | Available to order | 3 |
| 14 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 4 | $1.40 | Available to order | 4 |
| 15 | T1243322 Hose, Fuel Feed, Rubber, Assy | Hose, Fuel Feed, Rubber, Assy | 1 | $125.46 | Available to order | 1 |
| 18 | T1241982 Spring Clip, Fuel Rail | Spring Clip, Fuel Rail Not Illustrated | 1 | $5.88 | Available to order | 1 |
