Rear Bodywork & Seat
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2313183-FK Rear Bodywork, LH, Triumph Racing Yellow | Rear Bodywork, LH, Triumph Racing Yellow Includes Decal, Item 31 | 1 | $330.34 | Available to order | 1 |
| 1 | T2313183-PG Rear Bodywork, LH, Jet Black | Rear Bodywork, LH, Jet Black Includes Decal, Item 31 | 1 | $330.34 | Available to order | 1 |
| 2 | T2313182-FK Rear Bodywork, RH, Triumph Racing Yellow | Rear Bodywork, RH, Triumph Racing Yellow Includes Decal, Item 32 | 1 | $330.34 | Available to order | 1 |
| 2 | T2313182-PG Rear Bodywork, RH, Jet Black | Rear Bodywork, RH, Jet Black Includes Decal, Item 32 | 1 | $330.34 | Available to order | 1 |
| 3 | T2313007 Undertray Moulding | Undertray Moulding All Except IN | 1 | $51.25 | Available to order | 1 |
| 3 | T2313017 Undertray Moulding | Undertray Moulding IN Only | 1 | $104.09 | Available to order | 1 |
| 4 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 8 | $5.24 | Available to order | 8 |
| 5 | T3350161 Nut, Captive, M5 | Nut, Captive, M5 | 4 | $4.84 | Available to order | 4 |
| 7 | T3350129 Nut, Captive, M5 | Nut, Captive, M5 | 4 | $3.61 | Available to order | 4 |
| 8 | T2303943 Rear Frame Infill, LH, Rear | Rear Frame Infill, LH, Rear | 1 | $27.18 | Available to order | 1 |
| 9 | T2303944 Rear Frame Infill, LH, Front | Rear Frame Infill, LH, Front | 1 | $27.18 | Available to order | 1 |
| 10 | T2303946 Rear Frame Infill, RH, Rear | Rear Frame Infill, RH, Rear | 1 | $27.18 | Out of Stock | Notify Me |
| 11 | T2303947 Rear Frame Infill, RH, Front | Rear Frame Infill, RH, Front | 1 | $27.18 | Available to order | 1 |
| 12 | T2313011 Seat Bridge, Moulding | Seat Bridge, Moulding | 1 | $45.61 | Available to order | 1 |
| 13 | T3205062 Bolt, HHF, Lghtd, M6 x 12, Slv | Bolt, HHF, Lghtd, M6 x 12, Slv | 4 | $4.46 | Backorder — Early November 2026 | 4 |
| 14 | T3350111 Nut, Captive, M6 | Nut, Captive, M6 | 1 | $5.24 | Available to order | 1 |
| 15 | T3660175 Rubber Pad, 30 x 45 x 3 | Rubber Pad, 30 x 45 x 3 | 1 | $6.15 | Available to order | 1 |
| 16 | T2310816 Seat, Rider, Embroidered Silver | Seat, Rider, Embroidered Silver | 1 | $371.81 | Available to order | 1 |
| 17 | T2311511 Seat, Pillion, Embroidered Silver | Seat, Pillion, Embroidered Silver | 1 | $283.06 | Available to order | 1 |
| 18 | T2301364 Wrench, 124 x 54, Slot & Cross | Wrench, 124 x 54, Slot & Cross | 1 | $5.24 | Available to order | 1 |
| 19 | T2300634 Allen Key, 5mm | Allen Key, 5mm | 1 | $5.24 | Out of Stock | Notify Me |
| 20 | T2300912 Allen Key, 4.0mm | Allen Key, 4.0mm | 1 | $4.95 | Available to order | 1 |
| 21 | T3330726 Screw, Btn/Hd, M6 x 12, Slv | Screw, Btn/Hd, M6 x 12, Slv | 1 | $4.70 | Available to order | 1 |
| 22 | T2309004 Tool, Fork Adjuster | Tool, Fork Adjuster | 1 | $16.93 | Available to order | 1 |
| 23 | T2309831 Allen Key, 3mm | Allen Key, 3mm | 1 | $5.24 | Available to order | 1 |
| 25 | T2314002-PG Seat Cowl, Jet Black | Seat Cowl, Jet Black | 1 | $361.24 | Available to order | 1 |
| 25 | T2314002-FK Seat Cowl, Triumph Racing Yellow | Seat Cowl, Triumph Racing Yellow | 1 | $361.24 | Available to order | 1 |
| 26 | T2315521 Decal, MT2, Rear B/Work, LH, Crystal White | Decal, MT2, Rear B/Work, LH, Crystal White For Triumph Racing Yellow & Silver Ice Bodywork - Not Illustrated | 1 | $55.27 | Available to order | 1 |
| 27 | T2315522 Decal, MT2, Rear B/Work, RH, Crystal White | Decal, MT2, Rear B/Work, RH, Crystal White For Triumph Racing Yellow & Silver Ice Bodywork - Not Illustrated | 1 | $55.27 | Available to order | 1 |
| 28 | T2314006 Base, Seat Cowl | Base, Seat Cowl | 1 | $54.10 | Available to order | 1 |
| 29 | T3331436 Screw, S/Tap, Pan, Torx, 4 x 11, PT | Screw, S/Tap, Pan, Torx, 4 x 11, PT | 5 | $0.81 | Available to order | 5 |
| 30 | T2314109 Trim, Seat Cowl | Trim, Seat Cowl | 2 | $28.99 | Available to order | 2 |
| 31 | T2314004 Rubber Pad, Seat Cowl | Rubber Pad, Seat Cowl | 1 | $19.25 | Available to order | 1 |
