Fuel Tank Bodywork
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2316278-LT Upper Fuel Tank Panel, Mineral Grey | Upper Fuel Tank Panel, Mineral Grey Includes items 11, 12 & 13 | 1 | $319.93 | Out of Stock | Notify Me |
| 2 | T2311204 Infill, Fuel Tank, RH, Mldg | Infill, Fuel Tank, RH, Mldg | 1 | $27.90 | Available to order | 1 |
| 3 | T2311205 Infill, Fuel Tank, LH, Mldg | Infill, Fuel Tank, LH, Mldg | 1 | $27.90 | Out of Stock | Notify Me |
| 4 | T2311496-NW Fuel Tank Panel, Front, Crystal White | Fuel Tank Panel, Front, Crystal White | 1 | $172.95 | Available to order | 1 |
| 5 | T2307369 Rubber Foot, 4mm Deep | Rubber Foot, 4mm Deep | 2 | $3.93 | Available to order | 2 |
| 6 | T2313085 Clip, Bodywork | Clip, Bodywork | 8 | $2.60 | Available to order | 8 |
| 7 | T3330998 Screw, But/Hd, Skt, M6 x 12, 88, SS/Slv | Screw, But/Hd, Skt, M6 x 12, 88, SS/Slv | 2 | $4.58 | Available to order | 2 |
| 8 | T3020131 Grommet, 9 x 2 x 6 | Grommet, 9 x 2 x 6 | 4 | $2.14 | Available to order | 4 |
| 9 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 2 | $5.24 | Available to order | 2 |
| 10 | T3350123 Nut, Captive, M5, Non-Secured | Nut, Captive, M5, Non-Secured | 2 | $2.63 | Available to order | 2 |
| 11 | T2315252 Decal, Badge, Aluminium Slv/Sapphire Blk | Decal, Badge, Aluminium Slv/Sapphire Blk Included with item 1 | 2 | $18.75 | Out of Stock | Notify Me |
| 12 | T2314878 Decal, Tank Upper, RH, Ltd, White/Yellow | Decal, Tank Upper, RH, Ltd, White/Yellow Included with item 1 | 1 | $42.18 | Out of Stock | Notify Me |
| 13 | T2314877 Decal, Tank Upper, LH, Ltd, White/Yellow | Decal, Tank Upper, LH, Ltd, White/Yellow Included with item 1 | 1 | $42.18 | Out of Stock | Notify Me |
| 14 | T2315568 Decal, Tank Upper, Top, Moto2, White | Decal, Tank Upper, Top, Moto2, White Included with item 1 | 1 | $30.11 | Out of Stock | Notify Me |
