Rear Sets, Adj, Std
Parts (40)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9770046 Rear Sets, Adj, Std | Rear Sets, Adj, Std | 1 | $240.00 | Obsolete | View Details |
| 2 | A9770060 Plate, Main, LHS | Plate, Main, LHS | 1 | $76.00 | Obsolete | View Details |
| 3 | A9770061 Plate, Main, RHS | Plate, Main, RHS | 1 | $134.00 | Obsolete | View Details |
| 4 | A9770063 Plate, Upper, LHS | Plate, Upper, LHS | 1 | $31.00 | Obsolete | View Details |
| 5 | A9770064 Plate, Upper, RHS | Plate, Upper, RHS | 1 | $32.00 | Obsolete | View Details |
| 6 | A9770066 Heel Guard, LHS | Heel Guard, LHS | 1 | $66.00 | Obsolete | View Details |
| 7 | A9770067 Heel Guard, RHS | Heel Guard, RHS | 1 | $42.00 | Obsolete | View Details |
| 8 | A9770069 Lever, Rear Set, Gear | Lever, Rear Set, Gear | 1 | $42.00 | Obsolete | View Details |
| 9 | A9770070 Lever, Rear Set, Brake | Lever, Rear Set, Brake | 1 | $43.00 | Obsolete | View Details |
| 10 | A9770072 Foot Peg, LH R/Set, Folding | Foot Peg, LH R/Set, Folding | 1 | $55.00 | Obsolete | View Details |
| 11 | A9770073 Foot Peg, RH, R/Set, Folding | Foot Peg, RH, R/Set, Folding | 1 | $54.00 | Obsolete | View Details |
| 12 | A9770075 Bracket, Foot Peg, Rear Set | Bracket, Foot Peg, Rear Set | 2 | $38.00 | Obsolete | View Details |
| 13 | A9770076 Pin, Foot Peg, Pivot | Pin, Foot Peg, Pivot | 2 | $5.45 | Obsolete | View Details |
| 14 | A9770077 Peg, Bank Angle, 9mm | Peg, Bank Angle, 9mm | 2 | $6.48 | Obsolete | View Details |
| 15 | A9770078 Spring, Torsion, Foot Peg | Spring, Torsion, Foot Peg | 2 | $1.75 | Obsolete | View Details |
| 16 | A9770081 Linkage, Gear Lever, Assy | Linkage, Gear Lever, Assy | 1 | $71.00 | Obsolete | View Details |
| 17 | A9770082 Linkage, Brake Lever, Assy | Linkage, Brake Lever, Assy | 1 | $36.72 | Out of Stock | Notify Me |
| 18 | A9770083 Mount, Toe Peg, Rear Set | Mount, Toe Peg, Rear Set | 2 | $16.15 | Obsolete | View Details |
| 19 | A9770084 Pin, Toe Peg, Rear Set | Pin, Toe Peg, Rear Set | 2 | $27.00 | Obsolete | View Details |
| 20 | A9770085 Rubber, Toe Peg, Rear Set | Rubber, Toe Peg, Rear Set | 2 | $5.30 | Obsolete | View Details |
| 22 | A9770089 Rod, Gear Change | Rod, Gear Change | 1 | $49.00 | Obsolete | View Details |
| 23 | A9770090 Rod End, M6 | Rod End, M6 | 1 | $24.65 | Obsolete | View Details |
| 25 | A9770093 Mount, Brake Light Switch | Mount, Brake Light Switch | 1 | $1.20 | Obsolete | View Details |
| 26 | A9770094 Spring Mount, Brake Lever | Spring Mount, Brake Lever | 1 | $3.60 | Obsolete | View Details |
| 27 | A9770095 Spring Mount, Main Plate | Spring Mount, Main Plate | 1 | $11.70 | Obsolete | View Details |
| 28 | A9770096 Peg, Bank Angle, 16mm | Peg, Bank Angle, 16mm | 2 | $6.48 | Obsolete | View Details |
| 29 | A9770097 Peg, Bank Angle, 24mm | Peg, Bank Angle, 24mm | 2 | $6.48 | Obsolete | View Details |
| 30 | T3050321 Screw, Cap/Hd, M8 x 20, Slv | Screw, Cap/Hd, M8 x 20, Slv | 8 | $7.42 | Available to order | 8 |
| 31 | T3050334 Screw, Cap/Hd, M6 x 20, Slv | Screw, Cap/Hd, M6 x 20, Slv | 2 | $1.51 | Available to order | 2 |
| 32 | T3050333 Screw, Cap/Hd, M6 x 25, Slv | Screw, Cap/Hd, M6 x 25, Slv | 2 | $7.62 | Available to order | 2 |
| 33 | T3205781 Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | 1 | $1.62 | Available to order | 1 |
| 34 | T3050324 Screw, Cap/Hd, M8 x 1.25 x 35, Slv | Screw, Cap/Hd, M8 x 1.25 x 35, Slv | 1 | $4.74 | Available to order | 1 |
| 35 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 1 | $2.45 | Available to order | 1 |
| 36 | T3350300 Nut, M6 x 1.0, Slv | Nut, M6 x 1.0, Slv | 1 | $0.94 | Available to order | 1 |
| 37 | T3350304 Nut, LH, M6, Slv | Nut, LH, M6, Slv | 1 | $1.51 | Available to order | 1 |
| 38 | A9770098 Peg, Bank Angle, 40mm | Peg, Bank Angle, 40mm | 2 | $8.15 | Obsolete | View Details |
| 39 | A9770099 Peg, Bank Angle, 46mm | Peg, Bank Angle, 46mm | 2 | $8.15 | Obsolete | View Details |
| 41 | T3000302 Clip, 8mm, Clevis Pin | Clip, 8mm, Clevis Pin | 1 | $6.07 | Available to order | 1 |
| 42 | T3551282 Washer, M8, 8.4 x 15 x 1.6, Slv | Washer, M8, 8.4 x 15 x 1.6, Slv | 1 | $3.39 | Backorder — Late August 2026 | 1 |
| 43 | T3500135 Clip-E, Din 6799, Dia. 5.0 | Clip-E, Din 6799, Dia. 5.0 | 2 | $1.62 | Available to order | 2 |
