Emissions Control
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1250022 Reed Valve | Reed Valve | 1 | $54.20 | Backorder — Late August 2026 | 1 |
| 2 | T1250188 Cover, Reed Valve, Single | Cover, Reed Valve, Single | 1 | $36.58 | Available to order | 1 |
| 3 | T1250015 Reed Valve, Double | Reed Valve, Double | 1 | $59.87 | Backorder — Mid August 2026 | 1 |
| 4 | T1250196 Cover, Reed Valve, Double | Cover, Reed Valve, Double | 1 | $55.12 | Backorder — Late August 2026 | 1 |
| 5 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 4 | $4.55 | Available to order | 4 |
| 6 | T3700051 Hose Clip, Dia 18.1-20 x 8mm | Hose Clip, Dia 18.1-20 x 8mm | 4 | $2.25 | Out of Stock | Notify Me |
| 7 | T1250335 Kit, Bracket, SAI, Airbox | Kit, Bracket, SAI, Airbox > Eng No 629752 | 1 | $55.12 | Out of Stock | Notify Me |
| 7 | T1250444 Bracket, SAI, Valve | Bracket, SAI, Valve Eng No 629753 > | 1 | $20.93 | Out of Stock | Notify Me |
| 8 | T1250330 Hose, SAI | Hose, SAI | 1 | $13.10 | Available to order | 1 |
| 9 | T1250208 Hose, SAI, Formed | Hose, SAI, Formed | 1 | $48.49 | Available to order | 1 |
| 10 | T1250522 Solenoid, SAI | Solenoid, SAI | 1 | $98.85 | Available to order | 1 |
| 11 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 1 | $2.46 | Available to order | 1 |
