Footrests & Mountings (inc Street Triple Rx - JP Only)
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2081940 Control Plate, RH | Control Plate, RH | 1 | $92.25 | Available to order | 1 |
| 2 | T2081941 Control Plate, LH | Control Plate, LH | 1 | $92.25 | Available to order | 1 |
| 3 | T2081945 Heel Guard, RH | Heel Guard, RH | 1 | $49.41 | Available to order | 1 |
| 4 | T2081944 Heel Guard, LH | Heel Guard, LH | 1 | $49.41 | Available to order | 1 |
| 5 | T2082103 Footrest, Front, RH | Footrest, Front, RH | 1 | $75.74 | Available to order | 1 |
| 6 | T2082102 Footrest, Front, LH | Footrest, Front, LH | 1 | $75.74 | Available to order | 1 |
| 7 | T2085164 Peg, Bank Angle, 9.2mm | Peg, Bank Angle, 9.2mm | 2 | $14.07 | Available to order | 2 |
| 8 | T2080546 Pin, Pivot, Footrest | Pin, Pivot, Footrest | 4 | $6.55 | Available to order | 4 |
| 9 | T2080819 Return Spring, Footrest | Return Spring, Footrest | 2 | $6.29 | Available to order | 2 |
| 10 | T3500207 Circlip, Ext 8 X 0.89 | Circlip, Ext 8 X 0.89 | 4 | $2.85 | Available to order | 4 |
| 11 | T3051071 Screw, But/Hd, TX, S/S, M8 x 20 | Screw, But/Hd, TX, S/S, M8 x 20 | 2 | $6.55 | Available to order | 2 |
| 12 | T3050321 Screw, Cap/Hd, M8 x 20, Slv | Screw, Cap/Hd, M8 x 20, Slv | 4 | $7.42 | Available to order | 4 |
| 13 | T2081942 Footrest Hanger, Rear, RH | Footrest Hanger, Rear, RH All Mkts Excpt JP | 1 | $199.57 | Available to order | 1 |
| 13 | T2089717 Footrest Hanger, Rear, RH | Footrest Hanger, Rear, RH JP Only | 1 | $199.57 | Out of Stock | Notify Me |
| 14 | T2081943 Footrest Hanger, Rear, LH | Footrest Hanger, Rear, LH | 1 | $199.57 | Available to order | 1 |
| 15 | T2088203 Footrest, Rear, RH | Footrest, Rear, RH | 1 | $35.96 | Available to order | 1 |
| 16 | T2088202 Footrest, Rear, LH | Footrest, Rear, LH | 1 | $35.96 | Available to order | 1 |
| 17 | T2081674 Spring, Detent | Spring, Detent | 2 | $6.39 | Available to order | 2 |
| 18 | T2081675 Detent Ball | Detent Ball | 2 | $1.91 | Available to order | 2 |
| 19 | T2081672 Detent Plate | Detent Plate | 2 | $5.30 | Available to order | 2 |
| 20 | T3205781 Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv | 6 | $1.62 | Available to order | 6 |
| 21 | T2081946 Brace, Footrest Hanger | Brace, Footrest Hanger | 1 | $44.77 | Available to order | 1 |
