Triumph Street Triple Headlight Assembly > 480781 — OEM Parts Diagram

Triumph Waukesha is your source for OEM Triumph parts, accessories, and interactive schematics.OEM Triumph parts and schematics

Loading schematic...

What Our Customers Say

4.9 out of 5 based on 175 reviews

View all reviews →

“Thanks.”

B. BOUTET · SANTA MARIA, CA · Apr 2026

“So far excellent”

K. Colmark · Pharr, TX · Mar 2026

“great shop. easy to search/navigate for parts”

B. Hobratschk · Buda, TX · Feb 2026

“Very Smooth”

D. Haynes · GREENBACKVILLE, VA · Feb 2026

“Great inventory!”

S. Saenz · IDAHO FALLS, ID · Feb 2026

“This is my favorite Triumph OEM store on the planet”

C. Bozonier · VENTURA, CA · Jan 2026

#	Part Number	Description	Qty	Price	Status
1	T2702720 Headlight, LH, Dip	Headlight, LH, Dip AU, CY, HK, JP, MY, NZ, UK & ZA > 353064	2	$136.74	Obsolete	View Details
1	T2707575 Headlight Assy, LH Dip	Headlight Assy, LH Dip AU, CY, HK, JP, MY, NZ, UK & ZA 402348 > 428227	2	$152.11	Backorder — Late August 2026	2
1	T2702740 Headlight Assy, LH Dip	Headlight Assy, LH Dip AU, CY, HK, JP, MY, NZ, UK & ZA 428228 >	2	$152.11	Out of Stock	Notify Me
1	T2702725 Headlight Assy, RH/Sym Dip	Headlight Assy, RH/Sym Dip AR, BR, DE, ES, FR, GR, IT, SE, TW, CA & US > 352799	2	$152.11	Available to order	2 Ships within 3–7 business days
1	T2707576 Headlight Assy, RH Dip, Sym Dip	Headlight Assy, RH Dip, Sym Dip AR, BR, DE, ES, FR, GR, IT, SE, TW, CA & US 402329 > 428227	2	$152.11	Available to order	2 Ships within 3–7 business days
1	T2702745 Headlight, RH Dip, Sym Dip	Headlight, RH Dip, Sym Dip AR, BR, DE, ES, FR, GR, IT, SE, TW, CA & US 428228 >	2	$152.11	Available to order	2 Ships within 3–7 business days
2	T2700478 Protective Boot	Protective Boot	2	$3.33	Available to order	2 Ships within 3–7 business days
3	T2700401 Bulb, H/Lamp, Heavy Duty, 60/55w	Bulb, H/Lamp, Heavy Duty, 60/55w	2	$17.69	Available to order	2 Ships within 3–7 business days
4	T2500686 Subharness, Headlight	Subharness, Headlight	2	$26.56	Available to order	2 Ships within 3–7 business days
5	T2700210 Bulb, Parking Lamp, 12V 4W	Bulb, Parking Lamp, 12V 4W	2	$4.12	Available to order	2 Ships within 3–7 business days
6	T2700559 Ring support	Ring support	2	$8.09	Available to order	2 Ships within 3–7 business days
7	T2700560 Headlight rim	Headlight rim	2	$80.81	Available to order	2 Ships within 3–7 business days
8	T3330585 Screw, M4 x 30	Screw, M4 x 30	2	$1.62	Available to order	2 Ships within 3–7 business days
9	T3350069 Nut, M4	Nut, M4	2	$1.13	Available to order	2 Ships within 3–7 business days
10	T2700634 Headlight Bowl	Headlight Bowl	2	$98.85	Obsolete	View Details
11	T3330378 Screw, But/Hd, SKT, M10 x 1.5 x 40, SS	Screw, But/Hd, SKT, M10 x 1.5 x 40, SS	2	$12.04	Available to order	2 Ships within 3–7 business days
12	T3551283 Washer, M10, 10.5x18x1.6, Slv	Washer, M10, 10.5x18x1.6, Slv	2	$2.00	Available to order	2 Ships within 3–7 business days
13	T3350056 Locknut, Flgd, M10	Locknut, Flgd, M10	2	$9.41	Available to order	2 Ships within 3–7 business days
14	T2700717 Front Subframe	Front Subframe	1	$106.47	Available to order	1 Ships within 3–7 business days
15	T2700545 Headlight Clamp	Headlight Clamp	1	$33.74	Available to order	1 Ships within 3–7 business days
16	T2700569 Headlight Centre Pivot	Headlight Centre Pivot	1	$72.26	Available to order	1 Ships within 3–7 business days
17	T3050323 Screw, Cap/Hd, M8 x 30, Slv	Screw, Cap/Hd, M8 x 30, Slv	2	$4.74	Available to order	2 Ships within 3–7 business days
18	T3203030 Bolt, RHHF, Domed, M6 x 30	Bolt, RHHF, Domed, M6 x 30 > 447976	4	$3.50	Available to order	4 Ships within 3–7 business days
18	T3205070 Bolt, HHF, Lghtd, M6 x 30, Slv	Bolt, HHF, Lghtd, M6 x 30, Slv 447977 >	4	$2.37	Available to order	4 Ships within 3–7 business days
19	T3020034 Grommet, 15.5 x 6 x 11.5	Grommet, 15.5 x 6 x 11.5	4	$2.10	Available to order	4 Ships within 3–7 business days
20	T3010709 Flanged Sleeve, 6.4 x 11.5 x 10.75	Flanged Sleeve, 6.4 x 11.5 x 10.75	4	$4.12	Available to order	4 Ships within 3–7 business days
21	T3350012 Locknut, Flgd, M6, Black, Zinc	Locknut, Flgd, M6, Black, Zinc	4	$1.13	Available to order	4 Ships within 3–7 business days
22	T2702320 Moulding, Intake, Baffle	Moulding, Intake, Baffle	1	$33.93	Available to order	1 Ships within 3–7 business days
23	T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc	Screw, Pan/Hd, Tx, M6 x 12, Enc	1	$1.40	Available to order	1 Ships within 3–7 business days
