Rear Mudguard & Battery Box
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2306301 Battery Box | Battery Box | 1 | $252.83 | Available to order | 1 |
| 2 | T2306352 Number Plate Bracket | Number Plate Bracket | 1 | $58.54 | Available to order | 1 |
| 3 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv | 3 | $2.63 | Available to order | 3 |
| 4 | T3202325 Bolt, HHF, M8 x 43, Slv | Bolt, HHF, M8 x 43, Slv | 4 | $1.62 | Available to order | 4 |
| 5 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 2 | $1.72 | Available to order | 2 |
| 6 | T3701170 Plastic Rivet, Screw Type | Plastic Rivet, Screw Type | 2 | $1.21 | Available to order | 2 |
| 7 | T3330727 Screw, But/Hd, M6 x 20, Slv | Screw, But/Hd, M6 x 20, Slv | 1 | $3.39 | Available to order | 1 |
| 8 | T3330941 Screw, But/Hd, Skt, M5 x 16, Slv | Screw, But/Hd, Skt, M5 x 16, Slv | 4 | $6.73 | Available to order | 4 |
| 9 | T2305775 Main Number Plate Bracket | Main Number Plate Bracket | 1 | $87.47 | Available to order | 1 |
| 10 | T2306357 Indicator Mount | Indicator Mount | 1 | $89.35 | Available to order | 1 |
| 11 | T2306315 Mudguard Extension | Mudguard Extension AU, HK & NZ only | 1 | $72.26 | Available to order | 1 |
| 12 | T3200148 Bolt, RHHF, M6 x 30, Slv | Bolt, RHHF, M6 x 30, Slv | 2 | $4.45 | Available to order | 2 |
| 13 | T3350111 Nut, Captive, M6 | Nut, Captive, M6 | 1 | $4.92 | Backorder — Early August 2026 | 1 |
| 14 | T2306399 Heat Shield | Heat Shield | 1 | $59.87 | Out of Stock | Notify Me |
| 15 | T3350123 Nut, Captive, M5, Non-Secured | Nut, Captive, M5, Non-Secured | 2 | $2.48 | Available to order | 2 |
| 16 | T2306303 Moulding, Undertray | Moulding, Undertray | 1 | $94.11 | Available to order | 1 |
| 17 | T2703220 Bracket, US, Reflector | Bracket, US, Reflector | 1 | $9.02 | Available to order | 1 |
| 18 | T2700443 Reflector, Oval, Red | Reflector, Oval, Red | 2 | $6.14 | Available to order | 2 |
