Throttles, Injectors and Fuel Rail
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1240478 Throttle Body Assy | Throttle Body Assy | 1 | $2182.86 | Obsolete | View Details |
| 2 | T1242821 Fuel Injector Assy | Fuel Injector Assy | 3 | $220.55 | Available to order | 3 |
| 4 | T1240937 Throttle Position Sensor Kit | Throttle Position Sensor Kit | 1 | $167.31 | Available to order | 1 |
| 5 | T1242812 Idle Speed Control Assy | Idle Speed Control Assy | 1 | $266.18 | Available to order | 1 |
| 6 | T1240934 Fuel Rail Assy | Fuel Rail Assy ** Part No Longer Available ** | 1 | $209.71 | Obsolete | View Details |
| 7 | T1243001 Throttle Stop Kit | Throttle Stop Kit | 1 | $29.37 | Available to order | 1 |
| 8 | T1243115 Throttle Balancer Kit | Throttle Balancer Kit | 2 | $35.64 | Available to order | 2 |
| 9 | T1240253 Kit, Transition Piece | Kit, Transition Piece Each kit includes 2 x item 12 | 3 | $35.28 | Available to order | 3 |
| 10 | T3701055 Band Clamp, 55mm | Band Clamp, 55mm | 3 | $6.65 | Backorder — Early September 2026 | 3 |
| 11 | T3600118 O Ring, Transition Piece | O Ring, Transition Piece | 3 | $4.30 | Available to order | 3 |
| 12 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv Not required with kit T1240253 | 6 | $2.63 | Available to order | 6 |
| 13 | T1240241 Hose Assy, Fuel Feed, Rubber | Hose Assy, Fuel Feed, Rubber | 1 | $123.56 | Backorder — Restocking | 1 |
