Front Forks & Lower Yoke
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2044066 Stanchion Assembly, RH | Stanchion Assembly, RH | 1 | $1161.58 | Available to order | 1 |
| 2 | T2043221 Stanchion Assy, LH | Stanchion Assy, LH | 1 | $1161.58 | Backorder — Late August 2026 | 1 |
| 3 | T2049307 Stanchion, RH | Stanchion, RH | 1 | $1192.18 | Out of Stock | Notify Me |
| 4 | T2049326 Stanchion, LH | Stanchion, LH | 1 | $1192.18 | Out of Stock | Notify Me |
| 5 | T2049403 Seal & Bushing Set | Seal & Bushing Set | 2 | $93.40 | Out of Stock | Notify Me |
| 6 | T2049405 Rebound, Cartridge, RH | Rebound, Cartridge, RH | 1 | $813.98 | Out of Stock | Notify Me |
| 7 | T2045340 Compression Cartridge, LH | Compression Cartridge, LH | 1 | $813.98 | Available to order | 1 |
| 8 | T2049409 Spring Kit | Spring Kit | 2 | $204.24 | Out of Stock | Notify Me |
| 9 | T2049413 Outer Tube | Outer Tube | 2 | $649.54 | Backorder — Late August 2026 | 2 |
| 10 | T2044093 Lower Yoke Assembly | Lower Yoke Assembly | 1 | $411.10 | Out of Stock | Notify Me |
| 11 | T3050324 Screw, Cap/Hd, M8 x 1.25 x 35, Slv | Screw, Cap/Hd, M8 x 1.25 x 35, Slv | 4 | $4.74 | Available to order | 4 |
| 12 | T3800091 Bearing, Sac | Bearing, Sac | 2 | $33.95 | Available to order | 2 |
| 13 | T3600234 Dust Seal, Dia 55 | Dust Seal, Dia 55 | 1 | $8.34 | Available to order | 1 |
| 14 | T2042138 Cover, Headstock Bearing | Cover, Headstock Bearing | 1 | $10.90 | Available to order | 1 |
| 15 | T2040301 Adjuster Nut, M30, Lower | Adjuster Nut, M30, Lower | 1 | $28.50 | Available to order | 1 |
| 16 | T2042738 Rubber Washer | Rubber Washer | 1 | $1.13 | Available to order | 1 |
| 17 | T2040304 Locknut, M30 | Locknut, M30 | 1 | $20.60 | Available to order | 1 |
| 18 | T2044184 Washer, Tabbed | Washer, Tabbed | 1 | $10.78 | Out of Stock | Notify Me |
| 19 | T2700332 Reflector, Amber, Oval | Reflector, Amber, Oval Not illustrated | 2 | $6.39 | Available to order | 2 |
